Excellent U.V. Resistance ISO Certified Alkyd Resin Plant

What are Emulsions Emulsions are solvent free binders used in the preparation of paints and coatings. These are produced by the polymerization process where monomers are dispersed in an aqueous phase to get a uniform and stable emulsion. Paints and coatings based on emulsion systems are best in performance and are environment friendly.

Functions of Emulsions Excellent binding and hardness properties.Makes the paint elastic.Better sheen and gloss.Excellent U.V. resistance.High pigment loading capacity. Acrylic Emulsion in PaintsDifferent types of emulsions used in paints are pure and styrene acrylic emulsions. These emulsions are economical and are easily available. Emulsion based paints are free of solvents and are fast replacing solvent based paints due to its functionality and environmental friendly properties.

Manufacturing Process The processes involved in the formation of acrylic emulsion resin are complex and vary extensively. The production of low molecular weight dispersant product generates significant quantities of wastes.

Acrylic Emulsion Production Different acrylic emulsion formulations are produced by frigmaires acrylic emulsion resin plant. The steps involved in acrylic emulsion production varies greatly from product to product. Steps involved in the production of acrylic emulsion are listed below:
Raw materials for the emulsion line include monomers, additives, activators, and catalysts in liquid or solid form. For stabilization, some monomers are pre-mixed with inhibitors.

Catalysts are used for activating the monomers and initiating the desired reactions. Activators activate the catalysts, initiates the reaction, besides overcoming the effects of the inhibitors. Additives used in the mixture include detergents, dispersants, and pH-adjustment ingredients.
There after, the monomers are pumped from tanker trucks to monomer tanks for storage.
From the storage tanks, monomers are pumped to holding / premixing tanks, additive, activator, and catalyst holding tanks where mixing occurs.

The additives, activators, and catalysts can be directly added to the reactors without being mixed with monomers in their respective holding tanks.

Then, the raw materials are mixed together in one of three temperature- and pressure-regulated reactors where polymers are formed. The desired chemical reactions are initiated by addition of catalysts and are regulated with additives or by pressure and temperature adjustment.
The resulting acrylic emulsion polymers are pumped to blend tanks. Formalin is added in the blend as a preservative to control bacteria and mold growth and ammonia is added to for pH adjustment. Sodium hydroxide is another pH-adjustment chemical, added in the blend tanks.
Ingredients such as emulsions, emulsifiers, surfactants, binders and thickeners are added to modify monomer viscosity, to stabilize the polymers and to hold the polymers in suspension.Finally, deionized water is added to lower the solids content. After each polymer batch is processed, the blend tanks are flushed with deionized water which is further pumped to the plant's wastewater treatment system.

Wastes generated during different processes include composited absorbed monomers, burnable liquids, and off grade methylolacrylamide / acrylamide. Most of the composited absorbed monomer waste are generated from spillage during loading and unloading of the rail cars or from batch spills and reactor clean-ups.

Frigmaires an ISO 9001-2008 Company offers complete Plant on Turn Key basis along with the know how / training / formulation to Manufacture Paints, Inks, Dry Mix Mortars , Lubricants , Grease etc.

Over the years as the country was aiming towards self reliance and industrialisation, our firm jointly with our clients took up the challenge in finding solutions and developing cost effective equipment's & process for meeting their stringent requirements. Along with the growth of our clients grew our reputation, experience and knowledge of the manufacturing process and technologies which we wish to pass on to industrialists & entrepreneurs desirous of setting up new industries, expanding or diversifying, their present range of activity.

We have been working closely with our clients to tailor machines to their requirements. We offer trial runs on lab machines to get the manufacturing process right the first time.

Our manufacturing facilities are equipped with machinery and fabrication equipment. Over 90% of our jobs are carried out in house with a team of skilled work force and qualified engineers. Each stage of manufacture is closely inspected for quality and workmanship.
