Energy Storage System (20kWh)
Negotiable
1 (Min. Order)
You May Like
Product Details
| Place of Origin | Seoul, South Korea | Brand Name | Hande Co.,Ltd. | |
| Usage | UPS | Weight | 502 kg |
Product Description
Specifications
Fast charge in one cycle without cell balancing discharge process - Patented[Standard product – 20 kWh with 6 kW PCS]
| Battery | Rated storage energy | 20, 720 Wh |
| Cell type | 200 Ah lithium ion polymer | |
| Cell configuration | 14S2P200Ah | |
| Output voltage ranges | 38 VDC to 58 VDC | |
| Fast charge | 6,000 Watt | |
| Active cell balancing | CC/CV charging 6A (4.15V) | |
| AC output | Output power (Continuous) | 6,000 Watt |
| Waveform | True sine wave | |
| Phase | Single | |
| Frequency | 60±0.1 Hz | |
| Total harmonic distortion | < 5% | |
| Efficiency (CEC Weighted) | 93% | |
| Power factor corrected charging | 0.99 | |
| Emissions | FCC Class B | |
| UPS | Transfer time | 8 ms |
| Transfer relay | 60A | |
| Physical | Dimension (W x D x H) | 920 x 760 x 1,760 mm |
| Weight | 502 kg |
[Feature]
1) Fast charge in one cycle without cell balancing discharge process – Patented
2) 6 kW PCS (Schneider CE/FCC approved) integrated
3) Maintenance by cell module, not battery module
