automatic Two nozzles filling machine
- SHANGHAI
- Credit Card
You May Like
Product Details
| Condition | New | Application | Chemical | |
| Packaging Type | Bottles | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 220V | Power | 2KW | |
| Place of Origin | Shanghai, China | Brand Name | NPACK | |
| Model Number | NP-VF | Weight | 280KG | |
| After-sales Service Provided | Engineers available to service machinery overseas |
The machine was shrinked by shrinking wraping film, and then was packed in export standard and strong wooden cases.
Product Description
Specifications
two nozzles filling machine2.Specilizing in filling viscosity liquid
3.PLC control
4.Servo motor drive
two nozzles filling machine
Overview
The NP-EVF automatic linear viscous piston filling machine is design on the base of the NP-VF, it is also an extremely flexible filler capable of filling accurately and rapidly thin and middle viscosity liquids.
The NPACK automatic linear piston filler is manufactured with a 304 stainless steel frame and is capable of supporting 2 to 4 fill nozzles PLC Controls, touch screen, food grade contact parts, stainless steel and anodized aluminum construction, plus many more features come standard.
IT adds efficiency to any production line used in the cosmetic, food industry, specialty chemical, pharmaceutical, and personal care industries. Additional options are available for sanitary, hazardous, flammable and corrosive environments
Features:
304 Stainless steel construction , and the liquid contact parts are 316L stainless steel
All contact parts can be Teflon, Vinton and hoses per your requirements.
No bottle ,no fill, PLC control
The filling blocked nozzles are anti drops, silk, and auto cut viscous liquid
Accurate filling volume, within ±1% and a total bottle counter.
Easy to maintain, no special tools are required.
Special seals or hoses are adapted if the liquid are corrosive.
Diving nozzles for bottom up filling of foaming products if need
Bottle mouth can be located.
Options:
The top liquid tank hopper is optional if the liquid are middle viscous
Diving Heads
Drip Tray
Container Neck Locators
Manifold and Tank Upgrades
Capacity for Additional Fill Heads , max 4 filling nozzles
Polycarbonate Safety Guarding
Special electrical requirements
Additional remote E-stops
Sanitary, hazardous, flammable and corrosive environment construction
Applications
Liquid like water, or thin viscous and middle viscous
Specifications
Standard construction material: 304SS
Numbers of filling nozzles: 2-4 filling nozzles for optional
Standard power: 220V, 50/60HZ, single phase or 380V, 50/60Hz
Dimension and weight: subject to the model configuration and customer products
1 | Speed | 15-50bottles/min |
2 | Filling range | 100-1000ml,1000-5000ml |
3 | Measurement precision | ±1% |
4 | Working power | 220VAC |
5 | Air pressure | 6~8 |
6 | Air consumption | 1m³/min |
7 | Power rate | 0.8kw |
8 | Other devices power rate | 7.5kw(air compressor) |
9 | Net weight | 320 |
