Automatic Small Bottle Liquid Filling Machine 5ml
- SHANGHAI
- T/T Credit Card
You May Like
-
Automatic e-liquid filling and sealing machine
-
Syrup Filling and Capping Machine for Pharmaceutical
-
Automatic Oral Liquid Filling and Capping Machine for 5-25 ml Bottle
-
10-50ml Medical Liquid Filling and Capping Machine
-
Automatic Vial liquid Filling,Plugging and Sealing machine
-
automatic E liquid filling machine
Product Details
| Condition | New | Application | Medical | |
| Driven Type | Electric | Automatic Grade | Automatic | |
| Voltage | 380V | Power | 1.5KW | |
| Packaging Type | Bottles | Packaging Material | Wood | |
| Place of Origin | Shanghai, China | Brand Name | NPACK | |
| Model Number | NP-MFC Automatic Small Bottle Liquid Filling Machine | Dimension(L*W*H) | 2600*1300*1600 | |
| Weight | 450 | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Automatic Small Bottle Liquid Filling Machine was shrinked by shrinking wraping film, and then was packed in export standard and strong wooden cases.
Product Description
Specifications
Automatic Small Bottle Liquid Filling Machine1.filling and capping machine monoblock
2.suitable for filling liquid
Automatic Small Bottle Liquid Filling Machine
NP-MFC Full automatic Filling& capping machine monoblock .The machine adapt
316L stainless steel pump or peristaltic pump to fill different types of liquid,
the filling ,stoppering (rubber)and capping are in one machine.
Adapt for cosmetic, foodstuff , pharmaceuticals and chemical industry.
Feature
1.Adapt with pump which can fill viscosity liquid, high accuracy, easy to clean and sterilizing
2.The liquid contact parts can be different material to suit for different liquids.Filling Volume easy
adjustment, and micro adjustment equipped for each filling nozzles.
3.Bottom filling adapted for foamy liquids.
Technical parameters
Item | NP-MFC8/2 | NP-MFC4/1 |
Fillling nozzles | 4 | 2 |
Capping nozzles | 2 | 1 |
Filling range | 1-10ml,5-20ml,20-50ml,50-100ml | |
Ideal Filling range | 5-10ml,10-20ml,20-50ml | |
Cap types | Locked caps,screw caps,ROPP | |
Capacity | 3600~5000b/h | 2400~3000b/h |
Accuracy | ≤±1% | |
Capping rate | ≥99% | |
Voltage | 220V 50/60Hz | |
Power | ≤2.2kw | ≤1.2kw |
Air pressure | 0.4~0.6MPa | |
Net Weight | 1100kg | 900kg |
Dimension(mm) | 2600×1300×1600 | 2200×1300×1600 |
SHANGHAI NPACK AUTOMATION EQUIPMENT CO., LTD,
it is a professional manufacturer and supplier of various types of liquid, powder, paste,
granular packing machines since 2008.And in 2012, NPACK stepped into a new stage,
and supply one stop packaging solution. And turn key projects for customers,
now NPACK is one of the top brand in packaging machineries, and get a good Reputation
in the fields of Chemicals &cosmetics, Pharmaceuticals and Food industry.
In 2014,NPACK invested a new Plant for printing self adhesive labels( stickers labels in rolls) SHANGHAI RENYI PRINTING TECHNOLOGY CO.,LTD
NPACK Advantages:
One stop Packaging Solution
Professional Team, Top Service;
High quality Machineries;
Quality Inspection Service
What We Do
1. We are Manufacturing and Sale high quality packaging machineries.
2. Supply and design one stop packaging solution for pharmaceuticals, daily chemicals, cosmetics and food industry
3. Excellent after sales service system and machine guarantee system, all of the machines was guarantee For one year, and in one year, all of the broken spare parts are free if cause by the quality
Installation and Debugging
We will send engineers to carry out installation and debugging of the equipment in buyer's place if requested. The cost for International double ways air tickets, accommodations, food and transportations, medical shall be paid by Buyer for the engineers. Buyer shall fully cooperate with Supplier's engineer and make all the installation condition ready to work. such as: water, electricity, raw material etc.The normal debugging term is 3-7days, and the buyer should pay US$80/day per engineer.
Training
We offer machines training system, the customer can choose training in our factory or in customer workshop.The normal trainig days are 1-2 days.
Warranty
The sold machine will be guarantee in one year, in the guarantee year, any spare parts broken due to supplier’s quality issue the spare parts will be supplied free for customer, customer need to pay the freight cost if the parcel weight more than 500gram.The easy wearing out spare parts are not in the warranty terms, such as O rings, belts which will be supplied with the machine for one year using.
Vial filling and sealing machine for powder
Vial FIlling and sealing machine Liquid
Automatic HIgh speed round bottle labeling machine
Company Profile
Shanghai Zhiquan Automation Equipment Co., Ltd. is a professional manufacturer of various types of liquid, powder, paste, granular packing machines. Our main products: NPF series of filling machines, piston filling machines, overflow filling machines, gravity filling machines, weighing filling machines; NPC series of rotary capping machines, inline capping machines; NP series of powder, liquid, granular automatic packaging machines; and washing machines, ovens, unscramblers, aluminum foil sealing machines, inkjet printers, labeling machines, rotary tables, conveyor belts and other auxiliary equipment. Our machines are widely applied to daily-chemical, cosmetics, pesticides, oil, food, beverage, pharmaceutical and other industries. We always adhere to the principles of "technological innovation" and "excellent quality." We focus on product R&D while ensuring technology leadership and innovative features. All products are made of components and materials which are purchased from Germany, the United States, Japan, and South Korea, for the processing and assembling of our engineers and workers. They are the crystallization of our wisdom and labor. We use ISO9001:2008 quality management system and 5S on-site management practices to ensure the compelling product quality and accurate and timely supply. Our professional after-sale service team is ready to provide fast and efficient help for customers at any time. After years of development, we have accumulated rich experience in fluid packaging. Whether agent or cream, high-foam or corrosive products, we will provide you with the most reasonable solution in the first time. Excellent service and good reputation make us to be the leading supplier in this industry. Products have been exported to more than 50 countries and regions, including America, Europe, the Middle East, and Southeast Asia, being well received by our customers. We will confirm to you by excellent quality and efficient after-sale service. Zhiquan IS YOUR BEST CHOICE.
