Home > Products > PVC FIRE HOSE > Canvas Fire Hose Pipe
Canvas Fire Hose Pipe
- Tianjin/Shanghai
- T/T D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | Qinlong |
Product Description
Specifications
supply canvas fire hose pipe in1) Inner dia 25,40,50,65,80,100mm.
2)working pressure in 0.6,0.8,1.0,1.3,1.6,2.0, 2.5,3MPa
supply canvas fire hose pipe
1. warp: polyester yarn.
weft: polyester filament
2. weaving: plain/twill
3. lining: natural rubber,PVC,TPU/PU
4. features :
1) high pressure .resistance
2) anti-wear,aging
3) non-permeable
4) incurvation resistance
5) flexble and pliable
5. applications: fire fighting engines,extinguishing fire,high offical building ,mining, water transporation, agricultural irrigation
6. Technical Parameters
Model | Diameter | Working Pressure (MPa/Bar/Psi) | Test Pressure (MPa/Bar/Psi) | Burst Pressure (MPa/Bar/Psi) |
Length | |
Inner Dia (inch) | Inner Dia (mm) | |||||
C 8
| 1.5 | 40 |
0.8 / 8/120 |
1.6/16//240 |
2.4/24/360 |
10m-50m |
2 | 50 | |||||
2.5 | 65 | |||||
3.2 | 80 | |||||
4 | 100 | |||||
C 10
| 1.5 | 40 |
1 / 10/150 |
2/20//300 |
3/30/450 |
10m-50m |
2 | 50 | |||||
2.5 | 65 | |||||
3.2 | 80 | |||||
4 | 100 | |||||
C 13
| 1 | 25 |
1.3/ 13/190 |
2.6/26//380 |
3.9/39/570 |
10m-50m |
1.5 | 40 | |||||
2 | 50 | |||||
2.5 | 65 | |||||
3.2 | 80 | |||||
4 | 100 | |||||
C 16
| 2 | 50 |
1.6 / 16/240 |
3.2/32/480 |
4.8/48/720 |
10m-50m |
2.5 | 65 | |||||
3.2 | 80 | |||||
C 20 | 2 | 50 |
2 /20/300 |
4/40/600 |
6/60/900 |
10m-50m |
2.5 | 65 | |||||
3.2 | 80 | |||||
