Home > Products > Lollipop Machine > Automatic Servo Driven Lollipop Depositing Line with high quality
Automatic Servo Driven Lollipop Depositing Line with high quality
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
High Quality Automatic Lollipop candy machine with China Manufactory
-
Die-formed Irredular Lollipop Production Line
-
2016 New Style Technical Automatic Lollipop Candy Depositing Line with PLC control
-
2016 New Design Advance Technical Automatic Lollipop Candy Depositing Line
-
3D Lollipop Production line
-
Advanced Technology Servo Driven Lollipop Depositing Line
Product Details
Condition | New | Place of Origin | Shanghai, China | |
Brand Name | SHINWEI | Model Number | GD150B-S Servo Driven Lollipop Depositing Line | |
Application | Candy | Voltage | 380V | |
Power(W) | 18kW | Weight | 4000kg | |
Dimension(L*W*H) | 17m | Certification | CE;ISO9001 | |
Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Automatic Servo Driven Lollipop Depositing Line with high quality
Product Description
This whole line is produced according to GMP standard of food machinery; it is not only an ideal equipment which can produce out quality products with the saving of both the manpower and the space occupied ,but also help the candy manufacturer pass the GMP,HACCP,QS authentication easily.
PROCESSING CHART:
Raw material melting → Conveying → Filter → Storage → Constant syrup conveying →
Pre-heating → Micro-film vacuum cooking → Discharging → Mixing with flavor and Color
→ Depositing → Cooling → De-moulding → Conveying → Packing
Technical Parameter
Model | GD150B-S |
capacity(kg/h) | 250kg/Hr |
The candy weight | According to the type of sugar |
Speed | 25~30 n/min |
Demand steam | 250-300kg/h, 0.5~0.8MPa |
Compressed air requirements | 0.25m 3 /min, 0.4~0.6MPa |
Machine power | 18kW/380V |
Machine line length (m) | 17 |
Machine line weight(Kg) | 4000 |
Services
Automatic Servo Driven Lollipop Depositing Line with high quality
After-sale services for all the customers a. Free training of machine installation, operation and maintenance will be provided;b. Some spare parts will be sent together with the machine for free and some spare parts are always at favorable price for regular customers; c.Technical support will be offered by call, email or video etc; d.If necessary, our engineer will go to your factory for machine installation, adjustment or maintenance.
Shipment
Automatic Servo Driven Lollipop Depositing Line with high quality
Wooden packing
1.Product production is completed, by the quality inspection department to check
2.After inspection qualified, clean for whole machine
3.Packing: a. Inside the machine put desiccant b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4.Container:according to different products for reinforcement
Strength
Automatic Servo Driven Lollipop Depositing Line with high quality
Why choose us?a.Established in 1982, nearly 20-year experiences in the area of machinery manufacturing of food processing;b.Cooperate with well-known enterprises for some mechanical parts;c.Adopt environment-friendly and food-grade materials;d.Offer customized machineries and give suggestion for plant layout.
Company Information
Shanghai Target Industry Co., Ltd is the sales and service company for Shanghai SHINWEI Machinery Manufacturing Co., Ltd which is the first manufacturer to build the complete production line for depositing hard candies in China and has accumulated 40 years’ fabrication experience. It is also one of the leading and professional exporters in China by providing customers home and abroad with high quality confectionery, chocolate, biscuit and packaging machinery. Our machineries have been exported to East European, south America, middle east, southeast Asia.
As the first-class corporation for fabrication of confectionery, chocolate, biscuit and packaging machinery, Target Industry offers not only the advanced equipment with competitive and economical efficiency, but the whole solutions for the customer's demands also. We provide the design, production, assembly and commissioning work of small or medium confectionery and biscuit machines in accordance with the customer's specific requirements.
If you interested in our products,please contact us.I will spare no effort to help you!
For further information, please visit:
Best regards!
TARGET MACHINE
Wendy Wang
Contact Us
- Shanghai Shinwei Machinery Manufacturing Co., Ltd.
- Contact nameGANG LIU Chat Now
- Phone86-21-57459003,13524622057
- AddressNo. 7151, Puwei Rd.
