Home > Products > New Products > Hot sale 3kw mini turbine mini windmil
Hot sale 3kw mini turbine mini windmil
- shanghai
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Anhui, China | Brand Name | Hummer 3kw mini turbine | |
| Model Number | H4.6-3kw mini turbine | Type | Other, mini turbine |
Product Description
Specifications
3kw mini turbinerated power 3kw mini turbine from wind
type mini wind turbine
wind turbine prepositive design
Hot sale 3kw mini turbine/mini windmill/mini turbine generator with CE and UL
Product information
Hummer H4.6-3000W wind turbine generators is controlled by a comprehensive smart system .Through our years of monitoring on wind turbine operation ,we successfully develop an automatic control system for small and medium scaled wind turbines.
This smart system is able to automatically seek wind direction and constantly monitor :generator working status, rotation speed, generator temperature ,wind speed and direction etc .All data will be transmitted to control center .
When abnormal situation takes place ,our control center will instruct wind turbine to deflect from wind direction .After problem is released wind turbine will turn to face the wind direction again and resume generation .
Hummer H4.6-3000W wind generators, both off grid and grid tied are available.
Application of Model Hummer H4.6-3000W windmill generator
It can drive air-condition (3 to 3.5 horsepower), 1000W water pump or other resistive appliances (≤3KW).
Well used in:
Housing
Telecommunication Station
TV Transfer Station
Monitoring Station (military, hydrology, observatory)
Water-pumping Station
Specifications of 3000w wind turbine generator
Rated power(W) | 3000 |
Maximum output power(W) | 4500 |
Charging voltage (V) | DC 180V |
Blade quantity | 3 |
Rotor blade material | GRP |
Rotor blade diameter(m) | 4.6 |
Start-up wind speed (m/s) | 2.5 |
Rated wind speed (m/s) | 10 |
Rated rotating rate (r/min) | 400 |
Wind energy utilizing ratio (Cp) | 0.4 |
Generator output | single-phase frequency conversion AC |
Rated charging current (A) | 16 |
The maximum charging current (in a short time )(A) | 28 |
output AC frequency (Hz) | 0~360 |
Generator efficiency | >0.8 |
Wireless tower diameter(mm) | Φ397*Φ137*12000 (2pcs) |
Guy tower diameter(mm) | Φ140*3000*4 (4pcs) |
Tower height(m) | 12m |
The weight of generator(kg) | 60kg |
Battery 12V 150Ah/200Ah | 15pcs |
NOISE INDEX | LAeq=32 dBA 5m behind turbine@5m/s gusting |
