50KW off grid wind turbine system output three phase 380VAC HAWT

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Anhui, China		Brand Name	Hummer
Model Number	H12.0-50KW		Type	Wind Power Generator

HUMMER WIND TURBINE FEARURE:

Supercritical generator technology, 30% efficicency higher maximum, weightlighter, less volume.
SKF bearing, good quality with free maintenance.
Unique generator location at the nose cone of the wind turbine, good for heat disspation and decrease the wind resistance.
Siemens PLC smart control system with touchscreen tablet.
Multiple protection: Mechanical or electrical yawing, and manual operation etc.
Carbon brush to prevent the cables from wraping.
Airfoil blade design.
Anticorrosive processing material.
Grid tied or off grid optional.
Guyed tower or free standing tower, hydraulic tower are all available.
CE approved.

H12.0-50KW wind generator system, both off grid and grid tied are available.

Rated power (W)	50000
Maximum output power (W)	75000
Battery bank voltage (VDC)	400
Cut-in wind speed (m/s)	2
Rated wind speed (m/s)	11
Working wind speed (m/s)	2.5-25
Survival wind speed (m/s)	50
Generator efficiency	>0.92
Wind energy utilize ratio (Cp)	0.42
Generator type	Permanent Magnet Alternator
Generator weight (kg)	1200
Blade material/quantity	GRP/3
Blade diameter (m)	12.0
Over speed control	Yawing + Electromagnetic brake + Hydraulic brake
Shutting down method	Manual + Automatic
