3kw small maglev wind turbine system for home use

FOB Price

US$ 7,700 - 35,000 / Set

10 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Anhui, China		Brand Name	Hummer
Model Number	H4.6-3KW maglev wind turbine		Type	Wind Power Generator

CE and UL certification
10%~30% efficiency higher
1/3~1/5 smaller and lighter
Siemens PLC control system.

Rated power (W)	3000
Maximum output power (W)	4500
Charging voltage (V)	DC 180
Blade quantity	3
Rotor blade material	GRP
Rotor blade diameter (ft.)	16 (4.8m)
Start-up wind speed (mph)	6 (2.5m/s)
Rated wind speed (mph)	22 (10.0m/s)
Rated rotating rate (r/min)	265
Wind energy utilizing ratio (Cp)	0.4
Generator output	Frequency conversion AC
Rated charging current (A)	16.7
The maximum charging current (in a short time)(A)	28
Output AC frequency (Hz)	0~360
Generator efficiency	>0.8
Wireless tower diameter (in.)	Ø 15.6Ø 5.4 (Ø397Ø137mm) (2pcs)
Guy tower diameter (in.)	Ø5.5118.10.2 (Ø14030004mm) (4pcs)
Tower height (ft.)	39 (12m)
The weight of generator (lb)	132 (60kg)
Suggested Battery (Ah)	200/300
