5kw Price of Wind Turbine Generator Sales Manufacturer
- shanghai in china
- Credit Card
You May Like
-
Hummer 5KW Wind Power Generator for Residential Application
-
Low Price 5kw Intelligent Wind Generator Without Tail/Windrad/Windkraftanlage
-
Wind Power Generator 1kW/2kW/3kW/5KW Wind Turbine Windmill Generator for Farm/remote Houses
-
Intelligent Wind Turbine 5kw in Wind Turbine System for Home Use
-
5 Kilowatt Horizontal Wind Driven Generator
-
5000W Wind Turbine 5kw Wind Power Generator Kit for Houses
Product Details
| Place of Origin | Anhui, China | Brand Name | Hummer Wind Turbine Manufacturer | |
| Model Number | H6.4-5KW | Type | Wind Power Generator |
Product Description
Specifications
1.Light,small,high output efficiency2.Free maintenances
3.Intelligent protection
4.Siemens PLC control system
5.CE,UL,ISO
5kw cost of wind turbine generator sales in india
1. generator extremely small and light, low in sound, swift in startup, quick in dissipation, high in efficiency.
2. yaw shaft with the slip ring to ensure the rotation at 360 degree.
3. tower made of galvanised steel anti acid, salt proof, UV- proof.
4. wind vane and anemometer indicating wind direction and measuring wind speed, transmitting wind signal to PLC controller.
5. Siemens PLC controller receiving wind signal and operation signal , quick reaction and intelligent control.
6. brake block assembled in the flange of wind generator for hydraulic braking.
7.off grid inverter adopting SPWM technology, amorphous transformer and high frequency breaker, with hight converting efficiency, outputting stable frequency , stable voltage, filtering out noise,low distortion of pure sine wave.
8. grid feed inverter adopting MPPT and IGBT technologies, with high power generating capacity, wide AC voltage range.
9. dumping load metail dumping box, heat dissipation by air convection, without the fan and the controlling box.
10. rectifier rectifying and controlling the dumping load.
5kw wind turbine generator sales specifications
Rated power (W) | 5000 |
Maximum output power (W) | 7500 |
Battery bank voltage (Vdc) | 240 |
System output voltage (Vac) | 110/220/380 |
Start-up wind speed (m/s) | 2.5 |
Rated wind speed (m/s) | 10 |
Working wind speed (m/s) | 3-25 |
Survival wind speed (m/s) | 50 |
Generator efficiency | >0.8 |
Wind energy utilizing ratio (Cp) | 0.4 |
Generator type | Permanent Magnet Alternator |
Generator weight (kg) | 147 |
Blade material/quantity | GRP/3 |
Blade diameter (m) | Φ6.4 |
Speed regulation method | Yawing+Electromagnetism braking (Optional hydraulic braking) |
Shutting down method | Manual+Automatic |
Power curve
· It is 20%~30% Smaller in size and lighter in weight
· It has a 10%-30% Higher efficiency rating
· Greater than 10% Lower in noise
· Has a totally sealed generator making it suitable to operate in any weather condition.
· Remote control system adopted from 3kw to 100kw wind generator system
