Chinese Hot Sale 2kw Wind Turbine Generator Alternator

FOB Price

US$ 1,157 - 4,906 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Anhui, China		Brand Name	Hummer
Model Number	H3.8-2kw wind turbine generator alternator		Type	Wind Power Generator

Chinese hot sale 2kw wind turbine generator alternator

Product Feartures

1.With SCF generator technology, light in weight, small in size, and high in efficiency

2.With SKF bearings, free maintenance

3.The generator locating in nose cone, easy to radiate heat and reduce wind resistance

4.Siemens PLC control system with high reliability

5.CE tested and certified

6.Grid-tied,off-grid,wind-gird power supply system plans on an individual project basis

Main technical data

Rated power (W)	2000
Maximum output power (W)	3200
Charging voltage (V)	DC 120
Blade quantity	3
Rotor blade material	GRP
Rotor blade diameter (ft.)	12 (3.8m)
Start-up wind speed (mph)	7 (3.0m/s)
Rated wind speed (mph)	20 (9.0m/s)
Rated rotating rate (r/min)	450
Wind energy utilizing ratio (Cp)	0.45
Generator output	Frequency conversion AC
Rated charging current (A)	16.7
The maximum charging current (in a short time )(A)	28
Output AC frequency (Hz)	0~370
Generator efficiency	>0.8
Tower diameter (in.)	4.578.70.2 (11420004 mm) (5pcs)
Tower height (ft.)	33 (10m)
The weight of generator (lb)	55 (25kg)
Suggested Battery (Ah)	150/200

Power curve

All in One/Grid tied Inverter
