360 Degrees Round LED Light Rope Dia20mm

360 degrees Round LED Light Rope Packaging
-50meters/carton,
-gross weight : 20KGS per carton ;
-carton size: 36x36x30cm

LED NEON FLEX - HIGHLIGHTS :

1). 2 X Pure copper wire (0.75 sq . m . measure) as conducting wire, reducing line loss and volt. drop , more stable & safer.

2). Optically modified PVC extrusion : UV stable ; and PVC with heat/cool stabilizer, extremely high /low temp. resistant .

3). Complete kit including adapters, connectors & mounting clips enables easy installation.

4). Flexible, bendable, unbreakable & cuttable (cut at cutting marks).

5). SMD 2835 LED - 0.2W/LED (60mA)  -  Super Bright

6). No cold weather start problems or color shift.

7). Vivid NEON lighting effect, uniform light, no dots.

8). Waterproof IP65 , ok for indoor / outdoor use.

9). Eco-friendly, energy-effcient, durable, long-life.

LED NEON FLEX  : DOMED SHAPE  &  FLAT SHAPE

1). Domed-shape  _ size : 13.5x27mm

More details >>>

2). Flat  shape  _  mini size : 11.5x18 mm

More details >>>

LED NEON FLEX _  9 COLORS  :


LED NEON FLEX _  ACCESSORIES  :

LED NEON FLEX _  50m / roll / carton :

LED NEON FLEX  _ INSTRUCTION

* Use a heat gun to shrink the tubing, heat it evenly, until it 's snug to led neon flex and the edges are slightly beading from glue!

Loading Length :

Installation Precautions :

1. Do not puncture, cut, shorten, or splice LED Neon Flex outside of the designated cutting marks.

2. Do not roll out LED Neon Flex on rough surfaces and over sharp corners. This will scratch the PVC optic.

3. Do not use LED Neon Flex if outer jacket is damaged, loose connections, or if the wire is visible without insulation. Inspect LED Neon Flex periodically for damage.


4. Do not secure LED Neon Flex with staples, nails, or like means that might damage the insulation PVC material.

5. Do not install LED Neon Flex on/in places where it is subject to continuous flexing.

6. Do not operate/run LED Neon Flex in temperatures exceeding +45°C.

7. Do not operate AC240V+ / AC120V+ LED Neon Flex on circuits that do not have proper surge suppression or protection. High Voltage spikes will damage the LEDs.

8. Do not operate LED Neon Flex over the specified voltage or LED life degradation will be greatly increased.

9. Do not leave any part of the LED Neon Flex unsecured. Movement over time from weather can cause damage from continuous movement.

10. Do not cut LED neon flex when it's powered.

11. Do not over extend the mini Bend Radius Lateral of 40mm.

Our factory profile  :

Guangzhou Matt Electrical Lighting Co., Ltd.  is a professional LED Neon Flex manufacturer which integrates R&D, production, marketing etc service. Since our company's foundation, we've been working for LED lighting research and popularization. After years' development, our company has formed a complete set of standard systems in management, technology, quality and service. With over 6 years expenrience, we are confident to provide excellent quality and service to customers.

LED NEON FLEX _ CERTIFICATES  :

LED NEON FLEX  _ APPLICATIONS :

- Path & contour marking  _ Elegant interior decoration  _  Backlighting for  larger size  ad-signs

- Landscape outlines _ Signal lighting _ Swimming pool _ Car & motorcycle decorative lighting

- Architectural decorative lighting _ Archway Lighting _ Canopy Lighting  _  Bridge edge lighting

- Amusement park lighting _ theater lighting _ Emergency hallway lighting   _  Building outlines

- Auditorium walkway _ Stairway accent lighting _ Emergency Exit path lighting  _  Cove lighting

FAQ :

1. How often can led neon flex be cut ?

- AC240V _ cut intervals :  0.858m       ;     AC120V _  cut intervals :  0.429m

- DC24V  _  cut intervals :  0.143m       ;    DC12V    _ cut intervals  :  0.072m

   ( There're printed cutting marks on led neon flex, easy to cut. )

2. Max. run length ?


-  240V /120V  _ one power cable could load 50m in one continous line.

   ( 240V/120V , no need LED transformer, there's one small power convertor  on power cable to convert AC to DC)

- DC24V _ max. run length is 20m powered from one end ; 40m powered from both ends.

- DC12V _ max. run length is 10m powered from one end ; 20m powered from both ends.

  ( If running too many meters, it will cause the volt. drop, shorten the life of the LEDs and may damage the transformer. )

3. The difference : milky white or colored - PVC skin ?

-  The color with colored PVC skin looks _ deeper.

    ( Colored PVC skin _ red, blue, green, yellow , orange , pink  )

-  The color with milky white PVC skin looks _ slightly brighter.

4. Minimum bending radius ?

- Domed-shape LED neon flex _   R 40mm    ( sideways bending )

- Flat mini LED neon flex _   R 20mm    ( sideways bending )

5. Lead time ?

- Normal lead time : around 5-7 working days

6. Minimum order quantity ?

- One meter
