Pressure Sensor
- 1000 Piece / Pieces per Month
- Yantai
You May Like
-
AT 3351 Metal capacitive sensor,Manufacturer,metal capacitive transducer
-
AT3351 Metal capacitive sensor,Manufacturer,metal capacitive transducer
-
AT 3351 Metal capacitive sensor,Manufacturer,metal capacitive transducer
-
AT3351 Metal capacitive sensor,Manufacturer
-
AT3351 Metal Capacitive Sensor
-
AT3351 Metal capacitive sensor,Manufacturer,metal capacitive transducer
Product Details
Place of Origin | Shandong, China | Brand Name | AUTO | |
Model Number | AT3351 |
Carton
Product Description
Specifications
DP pressure sensorlow price
DP Pressure Transmitter
3051 Pressure Transmitter
Smart Pressure Transmitter
Detailed Product Description
Range : 0~0.2 kPa to 0~35MPa
Output signal : 4~20mA DC
Power supply : 24V DC other(10~30V DC)
Features of loading: relation equation of loading impedance RL and power voltage
Vs: RL <= 50(Vs-12)
Indicator : pointer-type linearity indication 0~100% scale mark or LCD indicator, LED indicator.
Explosion proof : a. explosion isolation d II BT4
b. intrinsically safe ia II CT6
Positive and negative shifts : after positive and negative shifts of zero absolute values of upper-and-lower-limit values of span and measuring range not exceed 100% of upper limit of measuring range.( smart type : turn down ratio 20:1,40:1,100:1)
Maximum positive shift is 500% of minimum adjusting span; maximum negative shift is 600% of minimum adjusting span.
Temperature range: amplifier operation temperature range: -29 ~ +93°c
(LT type: -25 ~ +70°c); measuring component of fill silicone oil: -40 ~ +104°c
flange type transmitter fill hi-temperature silicone oil: -20 ~ +315°c
normal silicone oil: -40 ~ +149°c
Static pressure : 4, 10, 25, 32MPa
Humidity : relative humidity 0~100%
Volume absorption : < 0.16cm3
Damping (phase step response) : For silicone oil, generally between 0.2s and1.67s, continuous and adjustable
Company Profile

Yantai Auto Instrument Making Company Limited is located in Yantai, a seaside resort in Shandong peninsula with charming natural beauty and convenient transportation. The company is specialized in developing, producing and marketing the process control instruments, possessing the complete ability of automatic system engineering. We mainly produce differential pressure transmitter, pressure transmitter, capacitive pressure sensor, RF admittance controller, tuning fork, level meter, winding pressure transmitter, magnetostrictive level gauge etc.. Which are widely used in the industries of electrical power, petroleum, metallurgy, medicine, food, brewing, textile, and build material etc.. The performance of the company are quickly increased through stable development for more than ten years since 1994. We adopt firstly in Shandong of the certification of ISO9001:2000 for the instrument company by Premier company in July,2001, and we build the quality management system which comply with the international approval. Our company is authorized to be the China Marketing General Agent of ultrasonic range finder by the Bohr company from Germany. We build up the casting department. And we mainly apply the silica sol precision-casting technology to produce many kinds of cast steel such as carbon steel, stainless steel, alloy steel etc. for better service of our instrument products. We meet the challenge of the using requirement of spot instruments relying on abundant technology strength, advanced equipment, super technology,strictly scientific quality management, continuously applying the advanced international technology and improving the products. And we guarantee the high quality and well-deserved reputation of the AUTO products. The director of the company is willing to create a promising picture with the people of vision. Faithfully invite the friends from the foreign and domestic countries to the heaven on earth for business discuss.
