Shaping machineSM-630/SM-1000H
- QINGDAO
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | HISING | |
| Model Number | SM-630/SM-1000H | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
SPECIFICATION OF SM-630/SM-1000H Shaping machine, PLEASE SEE THE PHOTO :
suitable for shaping plane and formed surfaces. High productivity can be obtained for shaping plane surface, T-slots and dovetail slots, etc. On narrow and long workpieces.
The ram mechanism adopts the guide unit with torsion-spring internally fixed. During the ram movement the cutting tool can adjusted to an arbirary position.
The total closed cam-ratchet unit is employed in the feed mechanism and rapid travel mechanism of the table featuring change of feed amounts without stopping the machine during cutting. A disk-type overload safety unit is used.
Owing to the adoption of swivel device with cam-curve groove different speeds can be selected arbitrarily.
Model | Unit | SM-630 | SM-1000H | |
Max. planing length | mm | 630 | 1000 | |
Max. distance between ram bottom and worktable surface | mm | 385 | 400 | |
Max. horizontal travel distance of Worktable | mm | 630 | 800 | |
Max. vertical travel distance of worktable | mm | 360 | 320 | |
Worktable | mm | 630×400 | 1000×500 | |
Travel of tool head | mm | 120 | 160 | |
Number of ram strokes/min | mm | 14.20.25 40.56.82 | 3-44stepless | |
Range of table power feed | Horizontal | mm | 0.2-2.5 12STERS | 0.25-5stepless |
Vertical | mm | 0.08-1.00 12STERS | 0.05-0.25stepless | |
Speed of table rapid traverse | Horizontal | m/min |
| 3 |
Vertical | m/min |
| 0.15 | |
T-slot width | mm | 18 | 22 | |
Main motor power | kw | 3 | 7.5 | |
N.W./G.W. | kg | 1750/1950 | 1870/2070 | |
