Home > Products > Silicone Rubber Heater > 220V CE/UL/ISO Silicone Rubber Heater Wire

220V CE/UL/ISO Silicone Rubber Heater Wire

FOB Price

US$ 0.5 - 1 / Meter

100 Meters(Min. Order)

Port NINGBO or SHANGHAI
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	cnjjwy
Model Number	WY-51	Type	Insulated
Application	Heating	Conductor Material	Other, heater strip
Conductor Type	Stranded	Insulation Material	Rubber

Product Description

Specifications

Quick and even heating, high thermal efficiency,long lifetime
Excellent thermal stability
Reliable insulativity
ODM&OE

Specifications

Quick and even heating, high thermal efficiency,long lifetime
Excellent thermal stability
Reliable insulativity
ODM&OE

Application Field

After the air cooler operates for some time, its blade will freeze, at the time, the antifreezing heating wire can be used for defrosting to let molten water discharge out of the refrigerator through the drain pipe.

As the front end of the drain pipe is installed in the refrigerator, defrosted water is frozen under 0°C to block the drain pipe, and heating wire is needed to install to ensure that defrosted water doesn't freeze in the drain pipe. The heating wire is installed in the drain pipe to defrost and heat the pipe at the same time to let water exhaust smoothly.

Characteristics

Complete water-proof design

Double-layer insulator

Mould pressing knot, flexibility

Silicon rubber insulator applicable scope: -60°C to +200°C

Heating Body		NiCr or Cu-Ni Alloy		Length/M	40W/M	50W/M
Tail End of Heating Body		Seal Tail End of Colloidal Silica		1	40W	50W
Maximum Surface Temperature		200°C		1.3	52W	65W
Minimum Surface Temperature		--60°C		1.5	60W	75W
Immergence Withstand Voltage		AC2500V V/min		2.0	80W	100W
Voltage	220-230V	Shape	Average7×5mm	3.0	120W	150W
Power	±5%	Output Power	40—50W/M	4.0	160W	200W
Tape Body Length	±5mm	Insulation Resistance	≥200MN	5.0	200W	250W
Tolerance	±10 %	Leaking Current	≤0.2MA	6.0	240W	300W
