Wind Power Grid Tie 24 Volt Inverter 500w
US$ 122 - 130
/ Piece
5 Pieces(Min. Order)
- NINGBO or SHANGHAI
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | CNJJWY | |
| Model Number | SUN-500G_WAL | Output Power | 401 - 500W | |
| Output Type | Multiple | Size | 332mm*265mm*135mm | |
| Weight | 3.5Kg | Input Voltage | 10.8V ~ 30V / 22V~60V | |
| Output Voltage | 190V ~ 260V | Type | DC/AC Inverters | |
| Output Frequency | 46Hz ~ 65Hz |
Product Description
Specifications
Place of Origin:Zhejiang, China (Mainland)Brand Name:CNJJWY
Model Number:SUN-500G-WDL
Certification:CE Certificates
Electrical Specifications:
| Model | SUN-500G-WAL/WDL | |
| Normal AC Output Power | 450W | |
| Maximum AC Output Power | 500W | |
| AC Output Voltage Range | Switch is at 230V Position | 190V ~ 260V |
Switch is at 115V Position | 90V ~ 130V | |
| AC Output Frequency Range | 46Hz ~ 65Hz | |
| Total Harmonic Distortion(THD) | <5% | |
| Power Factor | 0.99 | |
| DC Input Voltage Range ( Optional ) | 10.8V ~ 30V / 22V~60V | |
| Peak Inverter Efficiency | 92% | |
| Standby Power consumption | <1.5W | |
| Output Current Waveform | Pure Sine-wave | |
| MPPT Function | Yes | |
| Over Current Protection | Yes | |
| Over Temperature Protection | Yes | |
| Reverse Polarity Protection | Yes | |
| Anti-Island Protection | Yes | |
| Stackable | Yes | |
u Mechanical Specifications:
| Operating Temperature Range | -10 °c ~ 45 °c |
| N.W. | 3.5Kg |
| G.W | 4.0Kg |
| Dimension | 332mm*265mm*135mm |
