Home > Products > Inverter > Grid Tie Inverter for Wind Turbine 1000G_WAL Home Inverter Wind Energy Inverters
Grid Tie Inverter for Wind Turbine 1000G_WAL Home Inverter Wind Energy Inverters
US$ 235 - 245
/ Piece
10000 Pieces(Min. Order)
- Ningbo or Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | CNJJWY | |
| Model Number | SUN-1000G_WAL | Output Power | 801 - 1000KW | |
| Output Type | Multiple | Size | 405X275X123mm | |
| Weight | 3.5Kg | Input Voltage | 10.8V~30V / 22V ~ 60V | |
| Output Voltage | 190V ~ 260V | Type | DC/AC Inverters | |
| Output Frequency | 46Hz ~ 65Hz | Output Current | 4.5A |
Product Description
Specifications
home inverter advanced conversion technologysmall size, less weight,easy to use and causes less noise while working
| Model | SUN-1000G | |
| Normal AC Output Power | 900W | |
| Maximum AC Output Power | 1000W | |
| AC Output Voltage Range | Switch is at 230V Position | 190V ~ 260V |
Switch is at 115V Position | 90V ~ 130V | |
| AC Output Frequency Range | 46Hz ~ 65Hz | |
| Total Harmonic Distortion(THD) | <5% | |
| Power Factor | 0.99 | |
| Input Voltage Range | 22V~60V(test point is at the output of the rectifier) | |
| Peak Inverter Efficiency | 92% | |
| Standby Power consumption | <1.5W | |
| Output Current Waveform | Pure Sine-wave | |
| MPPT Function | Yes | |
| Over Current Protection | Yes | |
| Over Temperature Protection | Yes | |
| Reverse Polarity Protection | Yes | |
| Anti-Island Protection | Yes | |
| Stackable | Yes | |
u Mechanical Specifications:
| Operating Temperature Range | -10 °c ~ 45 °c |
| N.W. | 5.0Kg |
| G.W | 5.5Kg |
| Dimension | 405mm*275mm*123mm |
