Aluminum Extrusions Computer Wood Cuttimg Machine
- Qingdao sea port or any a port
 - Credit Card

You May Like
-


Different Extrusions Automatic Aluminum Wood Cutting Machine
 -


High Speed Sharp Cutter,automatic Wood Cutting Machine
 -


JInan Powerful Fast Speed Aluminum Pipe Profile Saw Cutting Machines With Pneumatic Control
 -


Jinan Powerful Aluminum Window Door Frames Double Head Mitre Saw Angle Saw Cutting Machines
 -


Jinan Powerful Automatic Wood Cabinet Edge Double Head Mitre Saw Angle Saw Cutting Machines
 -


Jinan Powerful Solar Boarder Double Head Mitre Saw Angle Saw Cutting Machines

Product Details
| Condition | New | Type | Frame Saw | |
| Use | Woodworking | Style | Vertical | |
| Place of Origin | Shandong, China | Brand Name | Jinan Powerful | |
| Model Number | QS-AC01 | Usage | Wood Cutting | |
| Voltage | 220V | Power(W) | 2.2kw | |
| Dimension(L*W*H) | 1260*820*1390mm | Weight | 350kg | |
| Certification | CE/ISO9001 | Warranty | One Year | |
| After-sales Service Provided | Overseas service center available |
Product Description
Aluminum extrusions computer wood cuttimg machinene
When you start it the spindle is at high speed , it can cut two angles 45degree at the same time , cutting precise angle , double head angle 45degree corner cutter can cut material of MDF board , solid wood board , aluminum, etc. It makes the cutting surface smooth , no glitches , without secondary processing.Double head angle 45degree corner cutter is suit for grain alloy, tungsten blades, circular saw blades.High efficiency of this cutter is yield of three times than generally singlehead machine , it’s the most practical and efficient aluminum machinery.Double head angle 45degree corner cutter is easy to operate , double saws start at the same time and cutting , too . Foot once time fixing your material , foot again cutting once . After sawing , it can reset automatically . One time can sawing two 45-degree angles , it can save your half time .
Specific information
* Cutting angle: 45.
* Maximum cutting width: 85mm
* Maximum cutting height: 120mm
* Spindle speed: 3800R / PM
* Applicable grain tungsten steel alloy blade circular saw blades: 355 * 25.4mm
* Working table size: 1260 * 300 * 800mm
* Motor power: 2.2KW * 2
* Working pressure: 6kg / cm2
* Dimensions 1260 * 820 * 1390mm
* Net / Gross weight: 350 / 430kg

Advantages
-- Taiwan WEINVIEW screen for operation,Japan's Mitsubishi of PLC, it can be set at the same time the size of 10, the largest number is 99.
-- The highest spped can be 25meter/min.
-- Line width(working width) is 9cm,hight is 80cm.
-- Automatic cutting, automatic transfer wood
-- sharp saw blade diameter is 14inch, double sawing, save your work time
-- It's not only cutting wood fream,but also cutting pvc material,aluminum extrusions.
-- All the working length is over 4 meters
-- The daily workload is suitable for more than 500 Moulding
-- The new self-developed, high-efficiency equipment of QS-AV01 Automatic 45 degree double head precise wood fream cutter
Q1: Are you a manufacturer ?
Yes.We have factory line and excellent skill.
Q2:How to order?
Please send us your purchase order by Email or Alibaba
We need to know the following information for your order:
1) Product information: Order Quantity,Specification(size ,material, color, length, Design styles)
2) Delivery time required.
3) Shipping information:Address,Phone number,Destination seaport/airport.
4) Send contact details if there is any in China.
Q3:What's payment?
* TT
* Western union
Q4: How about your shipping and package?
1)To machine we usually use the wooden case.
2)Shipping always by three ways:
Express(20days)- For few order, we will arrange international express delivery company for you
By sea(45days)- By sea at usual times.
By air(7days)- Air transport have DHL, UPS, FEDEX, TNT four international express delivery company, can provide door to door service.
