Home > Products > Focus IR camera > New Design 700TVL Nextchip NVP2090+811CCD 3D 360 Degree Universal Angle Bracket
New Design 700TVL Nextchip NVP2090+811CCD 3D 360 Degree Universal Angle Bracket
US$ 10 - 80
/ Piece
1 Piece(Min. Order)
- Shenzhen
- Credit Card
You May Like
-
External Focus/zoom Weatherproof Cctv Camera 42pcs IR LEDs 35m
-
High Quality 700TVL Sony Effio-A CCD Camera With OSD, Varifocal Lens
-
CCTV Surveillance Video Security Camera Waterproof IR Camera
-
New HD CVI Cctv Camera 2mp 1080p Cctv Camera hd Cvi Megapixel Analog Camera
-
Indoor hd Cvi Dome Camera 1 Megapixel 720p Hdcvi Dome Camera
-
2MP 1080p IR Bullet HD CVI CCTV Camera Waterproof Varifocal HDCVI Video Camera
Product Details
| Place of Origin | Guangdong, China | Brand Name | KAANSKY | |
| Model Number | KST-F718-N702 | Type | Analog Camera | |
| Style | Bullet Camera | Sensor | CCD | |
| Technology | Infrared | Special Features | Waterproof / Weatherproof |
Product Description
Features:
Horizontal resolution 700TVL
On-chip AFE
Enchanced Smart IR, 2D-NR
D-WDR, De-moire, Motion detection (48*15)
Dead pixel correction (white & black)
High light compensation; Lens shading correction
Parking line guide display; Privacy mask (8 zones)
OSD: English/Chinese<s>/Chinese/ Spanish/Russia/Japanese/
Spanish/Russia/Japanese/ Portuguese/German/French
RS-485(Pelco-D/P, Nextchip); Coaxial Comm.(Pelco-c)4
One button for OSD
| Model | KST-F718-C90 | KST-F718-N70 | KST-F718-E65 | KST-F718-EV800 | |
| Image Sensor | 1/3" COLOR Super HAD DIS | 1/3" COLOR NVP SONY CCD | 1/3" COLOR SONY EFFIO | 1/3" COLOR SONY EFFIO-V | |
| TV System | PAL/NTSC | ||||
| Image Resolution | PAL:976(H)×582(V), NTSC:976(H)×494(V) | PAL:976(H)×582(V), NTSC:976(H)×494(V) | PAL:976(H)×582(V), NTSC:976(H)×494(V) | PAL:976(H)×582(V), NTSC:976(H)×494(V) | |
| Horizontal Resolution | 900TVL | 700 TVL | 700 TVL | 800TVL | |
| CCD+DSP | DIS1099 DIS138+FH8520+IR CUT | 811ccd+EFFIO4140 673ccd+EFFIO4140 | 811ccd+EFFIO4140 673ccd+EFFIO4140 | 663ccd+EFFIO4141 ISRAEL | |
| Digital to Analog | 9Bit | ||||
| Minimum illuminator | 0.1LUX/F1.2 | ||||
| S/N Ratio | ≥48dB | ≥58dB | |||
| AES | 1/50-1/100,000sec(PAL),1/60-1/100,000sec(NTSC) | ||||
| WDR | D-WDR | D-WDR | D-WDR | SUPPER WDR | |
| DNR | 2D-DNR | 2D-DNR | 3D-DNR | 3D-DNR | |
| OSD | OSD | OSD | OSD | OSD | |
| White Balance | ATW/Manual/Auto | ||||
| AGC | Auto/Manual/Off | ||||
| BLC | ON/OFF | ||||
| Gamma Adjusting | 0.45 | ||||
| synchronization System | Internal Synchronization | ||||
| Video Output | 1.0Vp-p,75Ω | ||||
| IR | 42PCs F5mm | ||||
| IR Distance | 30-40 Meter | ||||
| LENS | 2.8-12mm | ||||
| Voltage | DC12V (9V ~ 15V) | ||||
| Operating Enviroment | ~ / 10% ~ 95%RH | ||||
| Size | Body: 190x98x80mm; Bracket: 165x100x85mm; | ||||
| Weight | 1.5kgs/1.25kgs | ||||
| packing | Color box: 300x174x131mm;18pcs per caton; Dimension: 625x530x425mm, appro. 0.141cbm; | ||||
