Home > Products > Focus IR camera > Outdoor Use 600TVL High Resolution 2.8-12mm Varifocal IR Camera
Outdoor Use 600TVL High Resolution 2.8-12mm Varifocal IR Camera
                            Negotiable
                                                            / Piece


                                                50 Pieces(Min. Order)

                    - Shenzhen
 - Credit Card

You May Like
-


420TVL 1/3'' SONY CCD 30M Focus Waterproof IR Color CCD Camera
 -


480 TVL 1/3'' SONY CCD 30M Waterproof Focus Lens IR Color CCD Camera
 -


Best Selling Day/Night Vision Focus IR Waterproof Camera
 -


960H HD Analog Camera IR Sony Effio 800TVL Waterproof Focus IR Bullet Camera
 -


1/3 Sony Ccd 700tvl Effio-E Low Price Cctv Bullet Camera
 -


Sony Super HAD II Hi Sensitive CCD&DSP hd Security Camera Support OEM Service

Product Details
| Place of Origin | Guangdong, China | Brand Name | KAANSKY | |
| Model Number | KST-F704 | Type | Other, Analog Camera, Varifocal IR Camera | |
| Style | Bullet Camera | Sensor | CCD | |
| Technology | Infrared | Special Features | Waterproof / Weatherproof |
Product Description
Specifications
1. Profession Manufactory2. CE, FCC and RoHS Certification
3. 2Years Warranty
4. Accept OEM
5. Fast delivery
outdoor use 700TVL high resolution 2.8-12mm Varifocal IR Camera
Product Description
1. IR Distance 45-50M
2. Adopting 42PCs x 5mm IR Leds
3. Standard lens: 4-9mm manual VF lens;(2.8mm-12mm / 9mm-22mm optional)
4. Dual glass, no IR diffusion and fog
5. IP66, outdoor installation
6. Cable-managed Bracket: to prevent external force of destruction such as cutting
| Model | KST-F704-S342 | KST-F704-N48 | KST-F704-N60 | KST-F704-E52 | KST-F704-E65 |
| Image Sensor | 1/3" COLOR SONY CCD  | 1/3" COLOR SONY Super HAD CCD  | 1/3" COLOR SONY Super HAD CCD  | 1/3" COLOR SONY EFFIO  | 1/3" COLOR SONY EFFIO  |
| TV System | PAL/NTSC | ||||
| Image Resolution | PAL:500(H)×582(V), NTSC:510(H)×492(V)  | PAL:752(H)×582(V), NTSC:768(H)×494(V)  | PAL:752(H)×582(V), NTSC:768(H)×494(V)  | PAL:752(H)×582(V), NTSC:768(H)×494(V)  | PAL:976(H)×582(V), NTSC:976(H)×494(V)  |
| Horizontal Resolution | 420TVL | 480TVL | 600TVL | 520TVL | 650TVL |
| Digital to Analog | 9Bit | 10Bit | 10Bit | 9Bit | 9Bit |
| Minimum illuminator | 0.1LUX/F1.2 | 0.1LUX/F1.2 | 0.1LUX/F1.2 | 0.01LUX/F1.2 | 0.01LUX/F1.2 |
| S/N Ratio | >48dB | >58dB | |||
| AES | 1/50-1/60,000sec(PAL),1/60-1/60,000sec(NTSC) | ||||
| WDR | — | D-WDR | D-WDR | D-WDR | D-WDR |
| DNR | — | 3D-DNR | 3D-DNR | 3D-DNR | 3D-DNR |
| OSD | — | OSD | OSD | OSD | OSD |
| White Balance | ATW | ATW/Manual/Auto | |||
| AGC | AUTO | Auto/Manual/Off | |||
| BLC | ON | ON/OFF | |||
| Gamma Adjusting | 0.45 | ||||
| synchronization System | Internal Synchronization | ||||
| Video Output | 1.0Vp-p,75Ω | ||||
| IR | 5mm*72pcs | ||||
| IR Distance | 50 Meter | ||||
| LENS | 4-9mm (2.8-12mm 9-22mm optional) | ||||
| Voltage | DC12V (9V ~ 15V) | ||||
| Operating Enviroment | ~ / 10% ~ 95%RH | ||||
| Demension | 225×105×190mm / BOX:280×120×120mm | ||||
| Weight | 1.25kg | ||||
| packing | 6pcs/ctn CBM: 65×40×32.5cm | ||||
Packaging & Shipping
