1/3'' Color Sony Effio high power IR leds cctv dot matrix camera
Negotiable
/ Piece
10 Pieces(Min. Order)
- shenzhen
- Credit Card
You May Like
-
900TVL 1/3'' CMOS 1099N camera varifocal dome camera
-
new design outdoor vandalrproof camera with aluminous case
-
700tvl cctv outdoor waterproof led Array ir dome camera
-
new design outdoor waterproof camera with aluminous case
-
1/3'' sony color waterproof cctv camera with 50M infrared distance
-
700TVL 1/3'' sony effio-p waterproof ir dome camera accept OEM
Product Details
| Place of Origin | Guangdong, China | Brand Name | Kaansky | |
| Model Number | KST-HI17 | Type | Analog Camera | |
| Style | Bullet Camera | Sensor | CCD | |
| Technology | Infrared | Special Features | Waterproof / Weatherproof |
Product Description
Specifications
IR Distance 50M2 pcs dot-matrix high power IR leds, integrated heat dissipation
6mm lens(8mm, 12mm optional)
Name: HI17 IR dot-matrix camera
Model: KST-HI17
Features:
1.IR Distance 50M
2.2 pcs dot-matrix high power IR leds, integrated heat dissipation
3.Standard match 6mm CS lens(8mm,12mm optional)
4.Dual glass, no IR diffusion and fog
5.IP66, outdoor installation
6.cable managed bracket: to prevent the external force of destruction such as cutting
| Model | KST-HI17-S342 | KST-HI17-N48 | KST-HI17-N60 | KST-HI17-E52 | KST-HI17-E65 |
| Image Sensor | 1/3" COLOR Sony CCD | 1/3" COLOR Super HAD CCD | 1/3" COLOR SONY Super HADCCD | 1/3" COLOR SONY EFFIO | 1/3" COLOR SONY EFFIO |
| TV System | PAL/NTSC | ||||
| Image Resolution | PAL:500(H)×582(V), NTSC:510(H)×492(V) | PAL:500(H)×582(V), NTSC:510(H)×492(V) | PAL:752(H)×582(V), NTSC:768(H)×494(V) | PAL:752(H)×582(V), NTSC:768(H)×494(V) | PAL:976(H)×582(V), NTSC:976(H)×494(V) |
| Horizontal Resolution | 420TVL | 480TVL | 600TVL | 520TVL | 700TVL |
| CCD+DSP | 633ccd+3142 | 633ccd+CP2030 | 639ccd+CP2040 | 633CCD+EFFIO4140 | 673CCD+EFFIO4140 |
| Digital to Analog | 9Bit | 9Bit | 9Bit | 9Bit | |
| Minimum illuminator | 0.1LUX/F1.2 | 0.1LUX/F1.2 | 0.1LUX/F1.2 | 0.01LUX/F1.2 | 0.01LUX/F1.2 |
| S/N Ratio | >48dB | >58dB | |||
| AES | 1/50-1/100,000sec(PAL),1/60-1/100,000sec(NTSC) | ||||
| WDR | — | D-WDR | D-WDR | D-WDR | D-WDR |
| DNR | — | 3D-DNR | 3D-DNR | 3D-DNR | 3D-DNR |
| OSD | — | OSD | OSD | OSD | OSD |
| White Balance | ATW | ATW/Manual/Auto | |||
| AGC | AUTO | Auto/Manual/Off | |||
| BLC | ON | ON/OFF | |||
| Gamma Adjusting | 0.45 | ||||
| synchronization System | Internal Synchronization | ||||
| Video Output | 1.0Vp-p,75Ω | ||||
| IR | 2x Hled | ||||
| IR Distance | 50Meter | ||||
| LENS | 6mm lens;(2.8-12mm, 9-22mm optional) | ||||
| Voltage | DC12V (9V ~ 15V) | ||||
| Operating Enviroment | ~ / 10% ~ 95%RH | ||||
| Demension | / BOX: | ||||
