Car Carrier Semi-trailer,transportating 8 cars
- 200 Set / Sets per Month
- TIANJIN QINGDAO SHANGHAI
- T/T Credit Card
You May Like
-
40 ton three axles Lowbed Semi-trailer for carrier heavy equipments and construction machinery
-
ST9401TJZ Tri-axle Flatbed Semi-trailer from factory for sale
-
20FT,40FT Container carrier semi trailer for sale
-
Four Axles Container Carrier Flatbed Semi Trailer
-
Two axles Low Bed Semi-trailer to transport construction machinery and heavy duty equipments and machines
-
20ft,40ft,45ft,48ft,53ft container carrier skeleton type semi-trailer which transport containers
Product Details
| Type | Semi-Trailer | Material | Steel | |
| Certification | Other, ISO,CCC | Size | 17000mm*2500mm*3950mm | |
| Max Payload | 8 units | Place of Origin | Shandong, China | |
| Brand Name | LUFENG | Model Number | ST9161TCL |
Product Description
Specifications
Car Carrier Semi-trailer ST9161TCL1.high quality
2.advanced technology
3.refined service
Car Carrier Semi-trailer ST9161TCL
Main Description | ||||||
Overall Dimension (L* W *H) | 17000mm*2500mm*3950mm | |||||
King pin setting | 1590mm | Wheelbase | 10850mm+1350mm | |||
Ground clearance | 200mm | Track | 2203mm | |||
Height of loading surface | 435mm | |||||
Running Gear | ||||||
Suspension | Mechanical suspension with 3-pcs leaf spring | |||||
Hubs | Cast steel 10 studs | |||||
Rim & Tire | Rim 7.5-20, 4 units tire 10.00R20, | |||||
Axles | 2 units ANHUI 10T concave axles | |||||
Brakes | Dual lines pneumatic brake system, 30/30 chambers, air-actuated | |||||
Under Frame | ||||||
Main Beam | I shape, Mild Alloy (16Mn) by Automatic submerged arc welding, welded on left and right sides | |||||
Cross beam | Mild Alloy Q235 | |||||
King pin | 50# (2'') welded on plate (optional 90# ) | |||||
Landing Gear | Static capacity 15Ton | |||||
Body | ||||||
Lifting type of upper floor | Hydraulic and manual lifting mechanism | |||||
Quantity of carried cars | 8 units (4m per car) | |||||
Electrical & Paint | ||||||
Lights & Reflectors | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light | |||||
Wiring | 24V, 6 lines | |||||
Air/Elec. Connector | ISO standard air connector, 24V 7 pin plug socket | |||||
Color | Upon request | |||||
Other | Vehicle body with canvas | |||||
Loading Port: QINGDAO,TIANJIN,SHANGHAI or other ports at China
Payment term: by T/T,30% advanced payment, and balance before shipment by T/T ;
by L/C,50% deposit by T/T, and 50% by irrevocable L/C at sight
Delivery time: The goods shall be prepared for shipment within seven days after receiving balance payment by T/T
Min. order quantity: 1 set
Supply ability: 200 sets/month
