Home > Products > Parking Lot Light > IP65 LED Tri Proof Lamp Super Brightness Square Linear Vapor Dust Proof Light Fixtures
IP65 LED Tri Proof Lamp Super Brightness Square Linear Vapor Dust Proof Light Fixtures
- Shanghai
- T/T Money Gram Credit Card
You May Like
Product Details
| Type | LED Vapor-tight Fixture | Certification | CE ROHS UL DLC |
Product Description
The LFVT04 vapor tight LED linear fixture delivers 3900 lumens at 4 foot (1.2 meter) length. The LFVT04 LED linear fixture accepts 120-277VAC, consumes 38 watts and 48 watts and produces luminous intensity equivalent to 1x54W T5, 2x32W T8, or 70W HPS. Available in 0-10V dimming and occupancy sensor options, the LFVT04 vapor tight LED linear fixture is ideal for parking garage, canopy, transportation, school, hospital, cold storage and exterior retail environments where moisture or dust is a concern. Polycarbonate enclosure protects fixture while remaining easy to service and clean.
Performance Summary
Input voltage: 120-277VAC, 50/60Hz |
Input wattage: 38 watts and 48 watts (1x54W T5, 2x32W T8, or 70W HPS fixture equivalent) |
Efficacy: 100 LPW |
Lumen output: 3800 and 4800 lumens |
CCT: 4000K/5000K |
CRI: 70 min. |
L70 life: 50,000 hours |
Warranty: 5 years |



PHYSICAL SPECIFICATION | |
Length | 48” (1200mm) |
Width | 4.33” (110mm) |
Height | 3.39” (86mm) |
Housing material | Polycarbonate |
Finish | White |
MOUNTING AND WIRING | |
Mounting | Ceiling mount |
ENVIRONMENTAL SPECIFICATION | |
Operating temp. | -13-130°F (-25–54°C) |
Ingress protection | IP66 rated for dry/damp/wet locations |
ELECTRICAL SPECIFICATION | |
Input voltage | 120-277VAC, 50/60 Hz |
Input wattage | 38/48 W |
Power factor | 0.90 min. |
Total harmonic distortion | 20% max. |
OPTICAL SPECIFICATION | |
Luminous flux | 3800 lm 4800 lm |
Efficacy | 100 lm/W |
CCT | 4000K/5000K |
CRI | 70 min. |
R9 | 0 min. |
Lens | Polycarbonate |
LIGHTING CONTROL | |
Dimming capacity | Optional |
LONGEVITY AND WARRANTY | |
L70 life | 50,000 hrs. |
Warranty | 5 years |
LISTING AND CERTIFICATES | |
DLC (DesignLights Consortium) | |
UL, cUL | |
CE, RoHS | |
Pozeen, dedicated to deliver quality and value to our customers, is established in 2001 and has become a world leading innovator in developing, designing, producing, and distributing indoor and outdoor LED fixtures and lamps.
Pozeen has setup research and development (R&D) center in Shanghai and operates our ISO9001:2008 accredited manufacturing bases in Zhejiang and Shenzhen.
Our products have obtained DesignLights Consortium (DLC), Lighting Design Lab (LDL), UL, ETL, CE and RoHS certificates. We use advanced facilities and equipment during developing and manufacturing processes, and thanks for our skilled professional workers and quality control team, we successfully control the failure rate within 0.2%.
