18-20L Conical Barrel Closed Cans Production Line

Name and picture

Technical Specificatins

Slitting Machine GTIB-15

Max.sheet thickness:        0.5mm
Sheet Width  :               60-1050mm
Attached engine Power:   1.1kw
Net Weight:                    1100 mm
Dimension:          1500×1100×1200mm

Diameter Range:   Φ100-Φ300mm
Thickness :            0.20-0.35mm
Max.Width :               400mm
Capacity (cpm) :        ≤30
Net Weight:              650mm
Dimension:         1300*730*1330mm

Power :                 3N.380V/50Hz 15KVA
Welding speed:             ≤ 12m/min
Capacity :                     20~50cans/min
Welding Frequency :     100~250Hz
Diameter Range:           φ65~φ 300mm
Height Range:               70~ 400mm
Overlap:                        0.6~ 1 .2mm
Thickness:                     0.2~ 0 .38mm
Copper Wire Diameter: φ1.5~φ 1.7mm T2
Cooling Water:              ≥0.4MPa 10L/min
Net Weight:                            1300kg
Dimension :                   1350×1300× 1700mm

Hydraulic Expanding Coning Machine 3TD20

Seaming Machine GT4A39-R

Capacity :                           8-20cans/min
Lrregular Can(Ddiagonal): 50 -330mm
Thickness:                             ≤ 0.4mm
Height Range:                     60--400mm
Net Weight:                           800kg
Power of motor:                     2.2kw
Dimension :                      1000x600x1900mm

Single Head Ear welding Machine DN40B

Power:            3N38050HZ 40KVA
Thickness :            0.2—0.5mm
Capacity                 25cans/min
Compressed air: 300L/min 0.6Mpa
Electrode joumey:     50mm
Net Weight:              320kg
Dimension:            80*60*140mm

 Moulds

Botto 1 ,Lid 1,Openings 3
Ear Welding Moulds:1


Punching machine
