4-6 Gallon Square Can Packaging Machine Making Line

Name and picture

Technical Specificatins

Slitting Machine GTIB-15

Thickness:       0.18-0.5mm
Sheet Width : 60-1050mm
Capacity:        1.6 m/min
Power:             1.1kw
Net Weight:     1100 kg
Dimension:  1500×1100×1200mm

Automatic Round Shape Roller Machine CY400-AT

Diameter Range:    Φ100-Φ300mm
Thickness :                0.20-0.35mm
Max.Width :                  400mm
Capacity (cpm) :           ≤30
Net Weight:                  650mm
Dimension:           1300*730*1330mm

Welding Machine FB2000-A

Power :                        3N.380V/50Hz 15KVA
Welding speed:                      ≤ 12m/min
Capacity :                             20~50cans/min
Welding Frequency :              100~250Hz
Diameter Range:                   φ65~φ 300mm
Height Range:                          70~ 400mm
Overlap:                                   0.6~ 1 .2mm
Thickness:                               0.2~ 0 .38mm
Copper Wire Diameter:     φ1.5~φ 1.7mm T2
Cooling Water:                  ≥0.4MPa 10L/min
Net Weight:                                1300kg
Dimension :                    1350×1300× 1700mm

Hydraulic Four-side Pannelling Machine 3F18Y

Hydraulic Flanging Machine 3FB18

Range of production:     9 -20L
Thickness (mm) :         0.26-0.35
Power of motor :            5.5kw
Maximum oil pressure:   8Map
Capacity:               15—20cans/min
Net Weight :                  800kg
Dimension(mm): 1300×700×1100

Seaming Machine GT4A39-S

Capacity:                        15-20cans/min
lrregular Can(Diagonal):     50-330mm
Height Range:                    60--400mm
Thickness:                          ≤ 0.4mm
Net Weight :                       800kg
Power of motor :                 2.2kw
Dimension  :                 980×580×1900mm

 Single Head Ear welding Machine DN40B
