Home > Products > 1-4Liter Square Can Production Line > making tin box machine
making tin box machine
- 300 Set / Sets per Month
- shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Packaging Type | Cans, Barrel | |
| Packaging Material | Wood | Automatic Grade | Semi-Automatic | |
| Voltage | 380V | Power | 60KVA | |
| Place of Origin | Jiangsu, China | Brand Name | FIRST | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas | |
| Application | Other, Paint/oil/adhesive/chemical/food |
Product Description
Specifications
making tin box machine1 Delivery on time
2 Easy to operate, durable
3 1 year service
1 The complete production line
We manufacture and supply complete can making machine line.the follow production line is for 18L square can.
Name | Specifications |
Slitting Machine
| Max.Thickness: 0.5mm Sheet Width : 60-1050mm Power: 1.1kw Net Weight: 1100kg Dimension 1500×1100×1200mm |
Automatic round forming machine | Model CY400-AT Diameter range Φ75-Φ300mm Thickness 0.2-0.4mm Max width 450mm Capacity 20- 30cans/min Net weight 450kg Dimension 1300*730*1330mm |
Backward seam welding machine | Power 3N 380V/50Hz 15KVA Welding speed: ≤ 12m/min Capacity: 20~50cans/min Diameter Range: φ65~φ 300mm Height Range: 70~ 400mm Overlap:0.6~1.2mm Thickness: 0.2~0.38mm Copper Wire φ1.5mm T2 Cooling Water 0.3MPa 8-10L/min ≤20°C Net Weight: 1300kg Dimension 1350×1300×1700mm |
18L Square can forming machine | Range of production 9-20L Thickness (mm) 0.26-0.35 Power of motor 7.5kw Maximum oil pressure 10 Map Capacity 15—20cans/min Net Weight 700kg Dimension(mm) 1300×700×1100 |
18L Square can flanging machine | Thickness (mm) 0.26-0.35 Power of motor 5kw Maximum oil pressure 8Map Capacity 15—20cans/min Net Weight 500kg Dimension(mm) 1300×700×1100 |
18L Auto square can sealing machine | Capacity 13- 15cans/min Diameter φ50-φ280mm Max height 350mm Weight 1100kg Motor power 1.5kw Dimension 2700x950x1850mm |
Single-head spot welding machine | Power: 3N38050HZ 40KVA Capacity: 10-20cans/min Compressed air:500L/min 0.6Mpa Electrode journey: 75mm Net Weight: 300kg Dimension: 550*850*1350mm |
| Models |  |
| Press machine | |
2 Sample show-case
this is samples of chemical/paint can, oil barrels,food cans, adhesive cans,biscuit can etc. please supply the can size(diameter/height/thickness) or cans pictures.we will recommend the proper machine for you.
3 Company information
4 FAQ
1:0.25L-25L round or square can production line
2:Lead time:30 days
3:Guarantee:1 year
4:Payment:T/T,L/C,30% payment in advance,70% should be balance before shipment
5:Support customize(we can make the machine base on your drawing or samples
6:Installation and commissioning:support engineers overseas installation and commissioning
5 Our advantage
1:CE certificate
2:24 hours online service
3:Supply factory layout
4:Electrical components
PANASONIC PLC,MITSUBISH variable frequency governor and OMRON optical switch
from Japan.
SCHNEIDER electrical appliance components from France.
AIRTAC pneumatic component and YONGKUN motor from Taiwan.
LG air switch,contactor and circuit breaker from South Korea.
SEMIKRON control thyristors from German.
BOURNS potentiometer from America
6 To dear customers
Much thanks for you spare time to read this informations.hope this introduce had solved your questions.if not,pls feel free to contact me.our company was engaged in tin can making machine for 17 we have rich experience.on the other hand.most of electrical components are import world famous brand,so that can guarrantee quality.we will recomment the proper machine for you in professional view.
7 Contact way
choose one way you like,and send me by mail or call me or online.
