Product Details

Condition	New	Type	Wheel Tractor
By wheel	2WD	Usage	Farm Tractor
Drive Type	Gear Drive	Power(W)	35hp
Certificate	Other, ISO9001:2008	Brand Name	RY
Model Number	RY350	Place of Origin	Shandong, China
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

garden tractor RY350 tractor :

Main Features:

1. The use of a simple floor structure and an external divider is easy for maintenance;

2. The safety frame is optional;

3. The single-acting or double-acting clutch is optional;

4. The various gear configurations, such as 8+2, 8+8 are optional, and the velocity distribution is reasonable to meet different operating needs;

5. The synchronized shuttle shift is optional, and the operation is easy, flexible and reliable;

6. The operations of hydraulic steering, the mandrel cylinder front drive axle are easy and flexible.

Technical parameters
Drive type	*42**
Overall dimension(L * W * H)	334015002051
Wheelbase (mm)	1776
Track(front/rear)	1100-1300/960-1460
Track(front/rear) regulating method	adjustable /step
Min.Ground clearance(mm)	338
Min.operating weight (without cab)(kg)	1480

Counterweight (max)(front/rear)	60/180
Gears(forward/reverse/creeper)	8+2/8+8
Theoretical speed of each gear(forward/reverse)	1.72-26.02/2.25-10.39;1.72-26.02/1.61-24.24;
Engine
Brand	RD350
Engine type	In-line, four-stroke
Intake mode	Natural intake
Cylinder number	3
Bore	75
Stroke	105
Displacement(L)	1.81
Engine rated power kW@rpm	23.13
Rated speed	2400
Type of air cleaner	Dry or wet type
Type of cooling system	Forced water-cooled
Max. Torque@ revolving speed (rpm)	≥96/1650
Specific fuel consumption rate at rated conditions(g/Kw.h)	≤244
Fuel tank capacity (L)	29
Steering brake system
Steering brake system	Hydraulic
Type of steering gear	Cycloid orbitrol steering gear
Type of braking system	Dry type or disc type
Transmission system
Clutch type	Single action
Gearbox type	Two-axis mechanical gearbox
Gearbox shift mode	Shift sleeve
Type of central transmission	Spiral bevel gear type
Final transmission mode(front/rear)	External gearing or built-in type
Walking system
Frame type	Frameless
Tire Model (front/rear)	6.00-16/11.2-24
Working device
Type of hydraulic suspension system	Open-center, semi-separated or separated type
Type of linkage	Three point rear linkage
Linkage classes	Class I
Lift capacity(610mm point))kN	Ordinary Riser≥5.79
Regulating mode	Semi-separated lifter: force and position combination control; separated lifter:depth control and floating control
Type of PTO shaft	Rear semi-detached/rear detached type
The number of PTO shaft splines	6 splines/8splines
Outer diameter of PTO shaft spline	φ35/φ38
PTO shaft speed	540/760
