The Newest Technology Small Cheap Used Ice Maker Tube Ice Making Machine (3 Ton/24hours)
- Shenzhen Port China
- T/T Credit Card
You May Like
-
Used China Supplier Ice Makers Commercial Tube Ice Making Machines for Sale
-
Easy Installation China Top Supplier Commercial Ice Maker Tube Ice Making Machine Manufacturer
-
High Quality New Style Water Cooled Ice Maker Tube Ice Making Machine Manufacturers
-
Wholesale Cheap High Quility Automatic Ice Machines Ice Tube Maker Machines
-
China Top Supplier Commercial Quality 5 Tons Crystal Ice Tube Ice Machine Price
-
Best Stand Alone China Supplier Commercial Tube Ice Machine Ice Tube Makers Price
Product Details
| Condition | New | Capacity | 3 Ton/24h | |
| Place of Origin | Jiangxi, China | Brand Name | Icefocus | |
| Model Number | JJTIM-3 | Ice Shape | Other, tube | |
| Voltage | 380V/415V/440V-3p-50Hz/60Hz | Power(W) | 14.5 KW | |
| Dimension(L*W*H) | 1650*1300*2150 mm | Weight | 1280 KG | |
| Certification | Other, ISO, CE, SGS, CCC | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Jiujiang Ideal Imp. & Exp. Co.,Ltd is specializing in ice machines, cold room project, refrigeration
equipments items for more than 8 years in China since 2007. And the brand name "Icefocus" has
been registered for developing our business and agents in the world. We are supplying
"ICE MACHINES" including the following items:
(1) Flake ice machines: Fresh Water system 500kg/24hour to 60Ton/24hour.
Sea Water System 1Ton/24hour to 20Ton/24hour.
(2) Plate ice machines: 3Ton/24hour to 15Ton/24hour.
(3) Tube ice machines: 2Ton/24hour to 30Ton/24hour.
(4) Cube ice machines: Commercial Cube Ice Machines 23kg/day to 1000kg/day;
Industrial Cube Ice Machines 2Ton/24hour to 20Ton/24hour.
(5) Block ice machines: 1Ton/24hour to 20Ton/24hour.
Thanks for remembering our brand "ICEFOCUS" ,
Hight Quality Ice Machines and Cold Rooms Spokesman !
Our Brother Company "Hongkong Ideal Refrigeration Equipment Ltd."
(1) Edible ice factory.
(2) Port ice plant
(3) Coffee shop, bar, hotel, etc.
(4) Supermarkets, convenience shop and resturants, etc.
(5) Aquatic products and food fresh preservation.
(6) Logistic fresh preservation.
(7) Chemical and concrete projects.
Tube Ice Features :
(1) Special ice making method to remove water impurity, the ice is hard and powderless.
(2) The tube ice, in hollow tube shape, is transparent, sanitary and environment friendly.
(3) Several dimensions for your options. Outer diameter: Φ22, Φ29, Φ38, Φ41mm and customized to your special requirements.
(4) Compared with flake ice, the tube ice has longer melting time.
(5) Suitable for storing and transporting, and applicable for several fields.
Model
| JJTIM-1 | JJTIM-2 | JJTIM-3 | JJTIM-5 |
Ice Output
| 1 T/24hrs | 2 T/24hrs | 3 T/24hrs | 5 T/24hrs |
Cooling Capacity
| 11.9KW | 18.8 KW | 33.5 KW | 49.4 KW |
Input Power
| 6.21KW | 8.39KW | 14.5KW | 22.73KW |
Ice Machine Weight
| 950 KG | 1150 KG | 1280 KG | 1600 KG |
Ice Machine Diameter
| 1400*900*1950 | 1650*1300*2150 | 1650*1300*2150 | 1750*1400*2200 |
Condenser Size
| 1100*450*870 | 1100*500*870 | 2000*650*1145 | 2000*700*1145 |
Ice Tube Machine Quality Main Parts List :
Name | Brand | Origin |
Compressor | BOCK / BITZER | Germany |
Evaporator | Icefocus | China |
Virbration Absorber | Henrys | Korea |
Oil Seperator | ALCO | U.S.A |
Condenser | Greenhalgh | Australia |
Dry Filter | Danfoss / Castel | Denmark / Italy |
Solenoid Valve | Danfoss | Denmark |
Gas-Liquid Separator | Danfoss | Denmark |
Pressure Gauge | Liang Chi | Taiwan |
PLC Controller | Schneide | France |
Air Switch | Schneide | France |
