CNC Carbide Boring Bits
US$ 4.7 - 10
/ Piece
40 Pieces(Min. Order)
- any chinese port
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Sichuan, China | Brand Name | LILT | |
| Model Number | LILT2013 | Type | Core Drill Bit | |
| Material | Tungsten Carbide | Use | Wood Drilling |
Product Description
CNC Carbide Boring Bits
Machine/Application
Portable boring machines
Automatic boring machines
CNC machining centers
For chip free drilling of dowel holes in solid wood and wood-based panels
Design
2 negative spurs
Centering point
Cylindrical shank with clamping surface
Spiral with back guide
TCT- tipped
Plastic coated
Advantages
Chip-free edges thanks to spurs
Safe drilling thanks to centering point
Protection of the hole edge upon exacting thanks to spiral with back guide
Optimum chip evacuation thanks to plastic coating
Tool life increased up to fivefold compared to traditional dowel bits
Sizes available as follows:
| Total Length: 57mm | Total Length: 70mm | |||||||
| Dia of edge | Dia of handle | Dia of edge | Dia of handle | |||||
| 3mm | 10mm | 3mm | 10mm | |||||
| 4mm | 10mm | 4mm | 10mm | |||||
| 5mm | 10mm | 5mm | 10mm | |||||
| 5.5mm | 10mm | 5.5mm | 10mm | |||||
| 6mm | 10mm | 6mm | 10mm | |||||
| 6.5mm | 10mm | 6.5mm | 10mm | |||||
| 7mm | 10mm | 7mm | 10mm | |||||
| 8mm | 10mm | 8mm | 10mm | |||||
| 9mm | 10mm | 9mm | 10mm | |||||
| 9.8mm | 10mm | 9.8mm | 10mm | |||||
| 10mm | 10mm | 10mm | 10mm | |||||
| 10.2mm | 10mm | 10.2mm | 10mm | |||||
| 11mm | 10mm | 11mm | 10mm | |||||
| 12mm | 10mm | 12mm | 10mm | |||||
| 13mm | 10mm | 13mm | 10mm | |||||
| 14mm | 10mm | 14mm | 10mm | |||||
| 15mm | 10mm | 15mm | 10mm | |||||
| 16mm | 10mm | 16mm | 10mm | |||||
