Sightseeing Vehicles With Rain Curtain

Model: GG-6633
Passenger Capacity: 14
Power supply electric
Battery: 6V*12
Motor :72V5KW/DC or 51V7.5KW/AC
Controller: 72V400A or 72V550A
Charger: 72V25A full automatic high frequency charger

Max. Speed: 30km/h
Max .travelling range: 60-80km
Climbing capacity: 20%
Brake Range: 6.5
Minimum turning radius: 6.5m
Gross Weight: 1300kg
Carrying capacity: 1120kg

brakes: Four wheels hydraulic
braking system and independent parking brake
tire :165/70R13
Ground clearance: 130mm
Overall dimension(L*w*h) :4800*1520*2025mm

 Standard parts Front and rear lights, Rear view mirrors

Speedometer,Wiper

Optional parts AC system, Loud speaker, CD player, Weather enclosure, Side sunshade curtain,

Front disc brake, Power assisted steering system,

1. Standard color: White, yellow; arractive design and powerful in appearance , with strong carrying capacity and lower noise.

2. Standard feature: Front and Rear lights; Rear View mirrors; Electric Horn; Rustproof body structure

3. Small turning radius; and smart steering system ;Whole style steel rear axle;

4. Can be easy modified to transportation vechicles,

5. CE certificate for whole carts;

6. Import main parts :Curtis controller(From USA).

7. Four wheels hydraulic braking system and independent parking brake
