Home > Products > Polyester Round Slings > Dawson 6T endless round soft lifting rope sling

Dawson 6T endless round soft lifting rope sling

FOB Price

USD $2 - $12 / Piece

1 Piece(Min.Order)

Supply Ability 20000 Piece / Pieces per Month
Port Qingdao Shanghai
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	Dawson
Model Number	Web Sling	Type	Webbing Sling
Shape	Endless	Material	Polyester
Lifting Capacity	5-Ton	Sling Color	Red
Lifting Eye Type	Flat Eye	Certification	CE GS ISO

Product Description

1.Type: Single and multi-ply

2. Safety Factor: 5:1/6:1/7:1/8:1

3. Standard: ISO4878,EN14920-1

4. Certification: ISO9001, SGS, CE

Technical Parameter

Advantages & application

Our webbing lifting slings are manufactured from 100% high tenacity polyester material. They have the following benefits:

1)Lightweight. Ideal to carry around jobs or sites and can be folded away to save space unlike heavy chain slings.
2)Strong. Yaletech webbing slings made from polyester are capable of lifting extremely heavy loads.
3)Versatile. Yaletech webbing slings are capable of various lifting techniques including vertical, chock and basket technique.

Product Name	Dawson 6T endless round soft lifting rope sling
Material	100% high tenacity polyester
Width	25mm,30mm,50mm,60mm,75mm,90mm,100mm,125mm,150mm 180mm,200mm,240mm,250mm,300mm
Length	from 1m to 20,can be customized as require
W.L.L.	From 1Ton to 12 Ton or up
Safety Factor	Layer
Layer	1/ 2 /3/4 ply
Color	According to EN standard or as required
Standard	According to Machinery Directive 2006/42/EC and EN1492-1:2008
Elongation	>=7%
Lifting Eye types	1.Flat Eye 2.Reversed Eye 3.Folded Eye 1/2 Width from 1 Side 4.Folded Eye 1/2 width from 2 sides 5.Folded Eye 1/3 width
Remark	all above 5 lifting eye types are available.
Sample Delivery Time	Within 30 days after confirmed

Technical Data

Polyester	WLL1T	WLL2T	WLL3T	WLL 4T	WLL 5T	WLL 6T	WLL 8T	WLL 10T	WLL 12T
Straight life up to 45	1.400	2.800	4.200	5.600	7.000	8.400	11.200	14.000	16.800
Chocked life up to 45	1.120	2.240	3.360	4.480	5.600	6.720	8.960	11.200	13.440
Straight life 40-60	1.000	2.000	3.000	4.000	5.000	6.000	8.000	10.000	12.000
Chocked life 45-60	800	1.600	2.400	3.200	4.000	4.800	6.400	8.000	9.600
Color Purple Green	Yellow	Grey	Red	Brown	Blue	Orange	Orange	Orange	Orange

Cautious

-Do not exceed working load limit, prevent shock-loading.
-Where selecting a sling it is very important to consider the angles at which the sling will be used.
-Slings are subject to cutting when lifting items with sharp edges. In this case always use wear sleeves.
-Do not use a damaged sling.
-Never make knots in a sling.
-Never drag a sling from underneath a load that is resting on it.
-Chemical active environments can affect the strength of slings.
-Inspect slings weekly or more frequently depending on sling use.
-Always store slings in a cool dry and dark place when they are not in use for prolonged periods.
-Always read and understand the operating instruction before use.

The product Image

Our Company

Factory

Our Factory

Workshop

Our Workshop

Warehouse

Our Warehouse

Team

Our Team

Packing & Delivery

Packing Details : Shrink film per product, export durable carton, pallet, color box for each set at your option

Delivery Details : 3-30 days after order of webbing slings
