Home > Products > Barcode Printers > Label Printer USB Godex Printer G500

Label Printer USB Godex Printer G500

FOB Price

Negotiable / Piece

2 Pieces(Min. Order)

Port Sheznzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Type	Other, Thermal Transfer / Direct Thermal
Style	Black And White	Use	Barcode Printer
Interface Type	USB	Max Paper Size	108 mm
Black Print Speed	127 mm/s	Color Print Speed	33
Max. Resolution	203 dpi	Brand Name	Godex
Model Number	G-500U	Place of Origin	Taiwan, China

Product Description

Godex G500-USB

Product Description

Print Method
Thermal Transfer / Direct Thermal

Resolution
203 dpi (8 dots/mm)

Print Speed
5IPS (127 mm/s)

Print Width
4.25" (108 mm)

Print Length
Min. 0.16” (4 mm)**; Max. 68” (1727 mm)

Memory
8MB Flash (4MB for user storage) / 16MB SDRAM

Sensor Type
Adjustable reflective sensor. Fixed transmissive sensor, central aligned

Media
Types: Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width: 1” (25.4 mm) Min. - 4.64” (118 mm) Max.
Thickness: 0.003” (0.06 mm) Min. - 0.01” (0.25 mm) Max.
Label roll diameter: Max. 5” (127 mm)
Core diameter: 1”, 1.5”, 3" (25.4 mm, 38.1 mm, 76.2 mm)

Ribbon
Types: Wax, wax/resin, resin
Length: 981’ (300 m)
Width: 1.18” Min - 4.33” (30 mm - 110 mm) Max
Ribbon roll diameter.: 2.67“ (68 mm)
Core diameter: 1” (25.4 mm)

Printer Language
EZPL, GEPL, GZPL auto switch

Software
Label design software: QLabel-IV (for EZPL only), GoLabel (for EZPL only)
Driver: Windows 2000, XP, Vista, 7, Windows Server 2003 & 2008
DLL: Windows 2000, XP and Vista

Resident Fonts
Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable

Download Fonts

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable

Barcodes
1-D Bar codes:
Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM and GS1 DataBar

2-D Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code

Code Pages
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode (UTF8, UTF16)

Graphics
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software

Interfaces
USB
USB

Control Panel
Two bi-color status-LEDs: Ready, Status
Control key: FEED

Power
Auto Switching 100-240VAC, 50-60Hz

Environment
Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C)

Humidity
Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing.

Agency Approvals
CE(EMC), FCC Class A, CB, cUL, CCC

Dimension
Length: 11.2” (285 mm)
Height: 6.8” (171 mm)
Width: 8.9” (226 mm)

Weight
6 lbs (2.72Kg) ,excluding consumables

Options
Cutter Module
Label Dispenser
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder
