Paper Die Cutting Machine/paper Automatic Machine (HY-1050E)
- Shanghai and Ningbo
- T/T
You May Like
-
Fully Automatic Paper Machines/paper Rolls Slitting Machine (HY1400)
-
Sheet Cutting Machines/sheet Cutter/slitting Machines(HY-1400)
-
Automatic Sheet Cutting Machine/slitting Machine/roll Paper Cutting Machine(HY-1700)
-
Industrial Paper Cutting Machine Auomatic Paper Cutting Machine (HY-1700)
-
Fully Automatic High-speed Electric Paper Guillotine
-
New Product Program Paper Cutting Machine Made in China
Product Details
| Condition | New | Type | Die-cutting Machine | |
| Computerized | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | HY | Model Number | 1050E | |
| Voltage | 380V | Power(W) | 19KW | |
| Dimension(L*W*H) | 4.7*4*2.3M | Weight | 14T | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
1.Clearance agencies with high precision fan gear, so that the paper at high speed can still be a smooth and steady pass, while reducing the impact on the whole, improve the life of the machine.
2.die cutting the Ministry of New elbows bar linkage design, to ensure that the cutting pressure of up to 300 tons under the premise of the moving platform is more stable, improve the cutting of the stability and reduce the fill pressure.
3.tooth row imported from Taiwan aviation aluminum, greatly improve the positioning accuracy and life of the tooth row.
4.Electrical equipment:
The whole machine adopts imported PLC control, so that the circuit control will greatly reduce the failure rate. Machine fault diagnosis with large-format color touch screen display system monitoring, fault information and troubleshooting displayed on a screen fully realize human-machine communication.
Electrical components, optical detection all imported from Japan.
Packaging:Wooden Cases
| HY1050E Technical Parameters | |
| aximum paper (mm) | 1050 * 740 |
| Minimum paper (mm) | 400 * 360 |
| Paper specifications (g / m) | 80-1200g |
| Maximum paper thickness (mm) | ≤4 |
| Die cutting up to speed (r / h) | 7500 |
| Maximum working pressure (t) | 300t |
| Minimum incision size (mm) | 9.5 |
| Maximum die size (mm) | 1040 * 730 |
| Cutting precision (mm) | ± 0.1 |
| Total power (KW) | 19 |
| Machine total weight (t) | 14 |
