Count down timer Switch with 7 button
- 100000 Piece / Pieces per Month
- FOB NINGBO
You May Like
Product Details
| Place of Origin | Zhejiang, China | Model Number | HET06-R | |
| Max. Voltage | 120VAC,60HZ |
Product Description
Description
l The TIMER is a time switch that turns OFF the connected light or fan when the selected time expires. The light under the ON/OFF button illuminates while the switch is OFF. One of the button indicators is always lit to indicate the last used timer.
Features:
l Seven-button preset time switch
l Adjustable time delay: 1, 5, 10, 20, 30, 60 minutes
l Replaces a standard light or fan single pole switch
l Works with most common lighting types
l Ideal for closet, pantry, garage, laundry room, outdoor lighting and spa
Specification
l 120VAC, 60HZ
Load requirement: Incandescent lamp: 0-800 Watt
Fluorescent lamp: 0-800VAC
Motor Load: 1/4HP
Time Delay: 1, 5, 10, 20, 30, 60 minutes
Environment: Commercial indoor use only
Operating Temperature: 32°to 131°F (0°to 55°C)
Humidity: 95% RH, non-condensing
Testing & Code Compliance
l UL/CUL Listed device
l California Title 24
l ISO9001 Registered manufacturing facility
Button Function
Normally, the package we support is GENERAL BLANK package with MOQ 500pcs. We also have many experience in supporting OEM service to our dear customers for over 10 years with MOQ 2000pcs. Welcome to your inquiry.
