Home > Products > FLD274 SERIES > 100kva AC Alternator 230v/ 400v
100kva AC Alternator 230v/ 400v
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | FARRAND | |
| Model Number | FLD274C | Output Type | AC Three Phase | |
| Speed | 1500rpm | Frequency | 50Hz | |
| Rated Power | 80kw | Rated Voltage | 110V~690V | |
| Rated Current | Amps |
Product Description
100kva AC Alternator 230v/ 400v
A range of quality dual voltage three phase brushless alternators available in a variety of sizes and prices, so you can find the configuration that works best for your application.
These units provide self excitation and a stable output with the use of an automatic voltage regulator.
These alternators may be coupled to a prime mover (driving engine) either by a direct shaft to shaft coupling or by conventional belt and pulleys. The AC frequency of the output power is determined solely by the speed of rotation of the prime mover, the alternators must spin at 1500 RPM to generate 50Hz /60HZ power. They can be driven either clockwise or anti clockwise to suit your application.
Please note that the colour supplied may vary from that shown in the picture.BUT WE CAN MEET YOUR REQUIRMENTS.
| Rating Power Factor | 0.8/1 | |||
| Altitude | 1000m | |||
| Insulation Class | H | Excitation System | Shunt | |
| Lead Number | 12 | A.V.R Model | SX460/MX321/MX341/SX440/SX440T/AS440 | |
| Winding Pitch | 2 / 3 | Voltage Regulation | ±1% | |
| Ingress Protection | IP 22 / 23 | Transient Voltage Recovery Time(s) | ≤1.0 | |
| Waveform:NEMA-MG1 | ≤50 | Waveform:IEC-THF | ≤2% | |
| Ambient Temperature | 40° C | 40° C | 40° C | 40° C |
| Temperature Rise | 125° C | 150° C | 125° C | 150° C |
| Phase / Insulation | 3 Phase / H Class | 3 Phase / H Class | ||
| Frequency | 50Hz(1500rpm) | 60Hz(1800rpm) | ||
| Voltage ( V ) | 110~ 690v | 110~ 690v | ||
| Type | Capacity | Capacity | ||
| Rated capacity/kva | Rated power/kw | Rated capacity/kva | Rated power/kw | |
| FLD164A | 8.1 | 6.5 | 10.2 | 8.2 |
| FLD164B | 11 | 8.8 | 13.8 | 11 |
| FLD164C | 13.5 | 10.8 | 16.9 | 13.5 |
| FLD164D | 16 | 12.8 | 20.2 | 16 |
| FLD184ES | 20 | 18 | 25 | 20 |
| FLD184E | 22.5 | 18 | 28.8 | 23 |
| FLD184F | 27.5 | 22 | 34.4 | 27.5 |
| FLD184G | 31.3 | 25 | 37.5 | 30 |
| FLD184H | 37.5 | 30 | 46.9 | 37.5 |
| FLD184J | 40 | 32 | 50 | 40 |
| FLD224C16 | 42.5 | 34 | 52.5 | 42 |
| FLD224D16 | 50 | 40 | 62.5 | 50 |
| FLD224E16 | 62.5 | 50 | 72.5 | 58 |
| FLD224F16 | 75 | 60 | 87.5 | 70 |
| FLD224G16 | 85 | 68 | 100 | 80 |
| FLD274C14 | 100 | 80 | 125 | 100 |
| FLD274D14 | 114 | 91 | 138 | 110 |
| FLD274DL14 | 125 | 100 | 156 | 125 |
| FLD274E14 | 140 | 112 | 168 | 134 |
| FLD274FS14 | 150 | 120 | 187.5 | 150 |
| FLD274F14 | 160 | 128 | 190 | 152 |
| FLD274G14 | 175 | 144 | 213 | 170 |
| FLD274H14 | 200 | 160 | 245 | 196 |
| FLD274J14 | 225 | 180 | 281 | 225 |
| FLD274K14 | 250 | 200 | 320 | 256 |
| FLD444C14 | 250 | 200 | 320 | 256 |
| FLD444D14 | 294 | 235 | 380 | 305 |
| FLDK444D14 | 313 | 250 | 390 | 312 |
| FLD444E14 | 325 | 260 | 394 | 315 |
The Alternator is dynamically balanced , brushless type, screen protected, revolving field, self excited, self regulated through an AVR. The alternator has the following features:
1. +- 1.0 % Voltage regulation (max.) in static conditions
2. IP: 22 protection with insulation class H
3. Permissible overload of 10% for one hour in 12 hours of operation.
The generators have been designed for use in a maximum ambient temperature of 40℃ and altitude less than 1000M above sea level.
Arranges in order all voltages may obtain from the single wide wingding ,also namely(three -phase) and 4(single -phase) reorganizes through 12 terminals may obtain.
Other special voltage can be met by Farrand company.
Q. How much will the shipping of my order cost?
Our shipping costs are calculated depending on the total weight and measurement CBM of the items you wish to purchase and your destination.We always do our best to keep the shipping costs to a minimum.Our forwarder has a long contract with us,we can get a big discount for you.
Q.How long does a sample takes?
A. If we have in stock,a sample will be delivered less than 3days.
Usually a sample takes 10 days.Please contact us which type that you needs,we will show you delivery time immediately.
Q.What is the MOQ of the product?
Our MOQ can meets your promotional business very well.
Q.Do you accept OEM?
Yes,we do.We can match any your samples.
Q.What is the level of ingress protection?
Ingress protection 22 standard,IP23 can be choosed.
Q.How many types of AVR do you have?
Such as SX460,MX321,MX341,SX440,SX440T,AS440,etc.
Q.How long is your quality guarantee period?
A.All alternators are warranted for 24 months from the notify date of waiting transportation.
