50HZ AC Brushless Alternator Single Phase 220V generator From 6.5KW To 315KW

Brushless AC generator, suitable for operation at 1500 RPM, 170V and up to 454 Volts, 0.8 pf (lag) suitable for 50 Hz, 3 phase & 1 phase, 4 wire system. The alternator is designed and built to withstand tropical conditions. The alternator generally conforms to IEC 34-1/34-2 , BS 4999/5000 and IS: 4722-2001 with enclosures rating IP 23 is the standard version, satisfying IEC 34-5/IS : 4691/DIN VDE 0530-5 requirements. The Alternator is dynamically balanced , brushless type, screen protected, revolving field, self excited, self regulated through an AVR. The alternator has the following features:

1. +- 1.0 % Voltage regulation (max.) in static conditions

2. IP: 23 protection with insulation class H

3. Permissible overload of 10% for one hour in 12 hours of operation.

The generators have been designed for use in a maximum ambient temperature of 40℃ and altitude less than 1000M above sea level.

Arranges in order all voltages may obtain from the single wide wingding ,also namely(three -phase) and 4(single -phase) reorganizes through 12 terminals may obtain.

Other special voltage can be met by Farrand company.

Purchasing a FLD  Series from us will include the following specification at no additional cost:

· 4 Poles

· Three Phase or Single Phase

· power factor 0.8 / 1.0

· 1500rpm /1800rpm

· 50hz / 60hz

· Available voltage from 170v and up to 454v

· 4 lead alternator

· Class H insulation

· IP23 enclosure

· High efficiency

· Automatic Voltage Regulator

Below you will find all the specific models associated with the FLD series.If you have any questions or need pricing please contact us.

The advantage of our material:

· The rotors and stators with 100% copper wire.

· The enamelled wire is Essex by America.

· The silicon steel sheet we use is the products of Wugang Brand,800 Series.which is the most famous manufacture of steel.And its advantage is its magnetic flux is large and its iron loss is small.

· The main frame of the alternator and lead box are made of steel,the end cover is made of high strength cast iron.

· All the components of our factory,the stator,rotor and excitation will be dipping lacquer twice.

· The rope of best nylon to be used in all the rotors and stators.We promise the security of our products,the phenomenon of ribbon burst will never happen.

· The TWB bearings are useing in our products.

· All the rotors should be tested by dynamic balance of Germany to go on test of balance. All the products should be tested by specialized Test Room.

Information for AVR:

We have many types of AVR,such us SX460, SX440, SX421, MX341, MX321,etc.

· The main stator provides power for excitation of the exciter field via AVR.

· Output power of exciter's rotor is input to that of mains through 3-phase full wave rectifier.

· Connected with piezoresistance for restraining surge voltage and avoiding the impact caused by short circuit or parallel synchronization loss.

· Exciter's Stator is equipped with permanent magnetic steel, it can make generator starting smoothly in any occasions.

· Voltage regulation (0.5 %) and low frequency protection, exterior voltage adjustment of SX440, MX341 and MX321 suitable for the generator with permanent magnetic generator (PMG).

Features:

1.  Any permanent magnetic alternators,providing invariable excitation on all occasions.

2.  Easy to be connected with power network or other alternators.Standard 2/3 pitch windings check excessive midline current.

3. Balanced rotor with single or two sealed ball bearings.

4. Convenient installation and maintenance with easy access to terminals,rotating diodes and coupling bolts.

5.  Wide range of flange adaptor and single bearing coupling disc

6.  Meet leading standards.

1 100% copper wire

2 Strict quality control system

3 Competitive price

4 Good Service

Q. How much will the shipping of my order cost?
A.Our shipping costs are calculated depending on the total weight and measurement CBM of the items you wish to purchase and your destination.We always do our best to keep the shipping costs to a minimum.Our forwarder has a long contract with us,we can get a big discount for you.

Q.How long does a sample takes?
A. If we have in stock,a sample will be delivered less than 3days.
Usually a sample takes 5 days.Please contact us which type that you needs,we will show you delivery time immediately.

Q.What is the MOQ of the product?

Our MOQ can meets your promotional business very well.

Q.Do you accept OEM?

Yes,we do.We can match any your samples.

Q.What is the level of ingress protection?

Ingress protection 22 standard,IP23 can be choosed.

Q.How many types of AVR do you have?

Such as SX460,MX321,MX341,SX440,SX440T,AS440,etc.

Q.How long is your quality guarantee period?

A.All alternators are warranted for 12 months from the notify date of waiting transportation.

We take great pride in our work and in the wide variety of products that we offer. Our goods have been enjoyed great reputation at US market, European market and Mid-EAST market .Please be aware that
our production lead times depend on specific items and item quantities. Our success has been based
on our understanding of the demands and nature of promotional and marketing deadlines. That's
why we always ensure that every order is delivered on time.
