Home > Products > (I)Auto Hose > High pressure anti-corrosion low temperature resistant high temperature resistant air conditioning hose
High pressure anti-corrosion low temperature resistant high temperature resistant air conditioning hose
- 1200000 Meter / Meters per Month
- tianjin
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | sufeitr | |
| Model Number | 134a |
Product Description
Automotive ac Hoses R134a Air Conditioning Hose
Application scope: Air Conditioning Hose, which is also
called refrigerant pipe, is used in automotive cooling, air-conditioning systems, industrial air conditioners filling and refrigerant conveying.
The hoses can maximize the prevention of refrigerants because the layer in them has high and high anti-leakage effect. They are suitable for all refrigerants, including R12, R22, R502, R401 and R134a. They meet high standard requirement and they a Automotive ac Hoses R134a are the most ideal substitute goods to imported rubber hose.
Technical standards: SAE J2064.
Appearance: Smooth surface, red, blue and yellow.
Specification of air conditioning hose
| Size | Inside Diameter | Outside Diameter | Working Pressure | Burst Pressure | Band Radius | Weight |
| Inch | mm | mm | Max. Mpa | Min. Mpa | Min. mm | g/m |
| 5/16 | 8.2±0.4 | 15.2±0.5 | 3.5 | 28 | 55 | 146 |
| 13/32 | 10.2±0.4 | 17.2±0.5 | 3.5 | 22 | 65 | 172 |
| 7/16 | 11.5±0.4 | 18.4±0.5 | 3.5 | 23 | 70 | 196 |
| 1/2 | 13.2±0.4 | 20.8±0.5 | 3.5 | 20 | 75 | 231 |
| 5/8 | 15.5±0.4 | 22.8±0.5 | 2.0 | 18 | 85 | 257 |
| 3/4 | 18.5±0.4 | 27.5±0.5 | 1.5 | 18 | 100 | 367 |
