Home > Products > solar panel > China Hot sale 200w mono-crystalline solar module panel
China Hot sale 200w mono-crystalline solar module panel
- Shanghai/Ningbo
- T/T
You May Like
-
A-grade Cell High Efficiency Mono-100w Solar Panel for solar power system
-
High efficiency and Hot sale300w mono-crystalline solar module panel
-
Integrated Solar LED Street Light all in one 60w
-
Integrated Solar LED Street Light all in one 80w
-
500w off-grid home solar system solar power system for residential solar energy
-
high efficiency 1000w off-grid solar power system/ home electricity power generator
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Jiutong | |
| Model Number | JT200W | Material | Monocrystalline Silicon | |
| Size | 1580*808*35 | Number of Cells | 72(6*12)pcs | |
| Max. Power | 200W |
Product Description
200
MONO-CRYSTLLINE
SOLAR PANEL
180—200 Technical Parameters
Model | 200 | 190 | 185 | 180 |
Vmp(V) | 35.0 | 35.0 | 35.0 | 35.0 |
Lmp(A) | 5.71 | 5.42 | 5.28 | 5.14 |
Voc(V) | 43.0 | 43.0 | 43.0 | 43.0 |
Lsc(A) | 6.49 | 6.32 | 5.98 | 5.81 |
Pm(WP) | 200 | 190 | 185 | 180 |
Operating Temperature | -40 to +85℃ | |||
Maximum System Voltage | 1000VDC | |||
NOTC | 48℃±2℃ | |||
Current Temperature Coefficient(%/k) | 0.06±0.01 | |||
Voltage Temperature Coefficient(mv/k) | -(155±10) | |||
Power Temperature Coefficient(%/k) | -(0.5±0.05) | |||
Type of output terminal | Junction Box | |||
Cable | 900mm, lamp(4.0mm²) | |||
Connection | Standard Plug and Sock | |||
Solar Cell | Mono-crystalline silicon solar cell 125mm*125mm | |||
Type of solar cell | Type P | |||
No. of cells and connections | 72(6*12) | |||
Dimension | 150*808*35mm | |||
Weight | 16kg | |||
Certificates | CE, ICE61215, TUV | |||
Application | Large and medium-sized solar power station, household solar power system, ect. | |||
