2015 High Drying Performance Coconut Fiber Rotary Dryer

Overview of coconut fiber dryer:

Coconut fiber dryer means to continuously feed wet coconut fiber into dry tubes with conveyor. Evaporate wet material moisture in the transmission and spread of high-speed hot air flow, getting dry products.

Coconut fiber dryer can be used for drying a wide range of biomass materials such as alfalfa, straw, sawdust, marigold, wood shavings, manioc waste, bagasse, colza cake and leaves, etc.

Structure of coconut fiber dryer:

Coconut fiber dryer is mainly composed of heating furnace, feeder machine, rotating tube, cyclone separator and draught fan.

Working principle of coconut fiber dryer:

Coconut fiber with high moisture content are fed into rotary cylinder; shovelling plates inside the drum walls raise up materials and these materials scatter down to move in a spiral forward style. During the constant raising up and scattering down, wet sawdust can absorb enough amout of heat, at the same time, the drying time is extended to achieve the best drying effects.

Structure of coconut fiber dryer:

Coconut fiber dryer is mainly composed of heating furnace, feeder machine, rotating tube, cyclone separator and draught fan.

Working principle of coconut fiber dryer:

Coconut fiber with high moisture content are fed into rotary cylinder; shovelling plates inside the drum walls raise up materials and these materials scatter down to move in a spiral forward style. During the constant raising up and scattering down, wet sawdust can absorb enough amout of heat, at the same time, the drying time is extended to achieve the best drying effects.

Features of coconut fiber dryer:

1. High drying strength, as the material is highly dispersed in the air, total surface area of particle is effective area.

2. Short drying time.

3. Simple structure, covering a small area, easy to construct and maintain.

4. Large capacity, high thermal efficiency.

Technical data of coconut fiber dryer:
