RFID Tire Tag Designed for Embedding in the Tire

 CMRFID is a  global leading RFID supplier. Founded in 2006, we have customers from more than 58 countries till 2014. Cmrfid Group based in Shanghai, branches Cmrfid Shanghai, Cmrfid Brazil and Cmrfid Dubai. We are major in RFID cards, tags , readers and solutions.

• Introduction of CM-101 tire tag
  1.Based on independent intellectual property development, adapt reader to work with global frequency range 860mhz~960mhz.
  2.Protocol: EPC Class 1 Gen 2/ISO 18000-6C
  3.Tags implanted in the tire in the tire molding process, it can be fully able to withstand the high temperature curing and high pressure. Structures design for firmness and flexibility make it possible to withstand the entire life cycle of the tire deformation and shear stress.
  4.RFID tags can be implanted steel tire or semi-steel tires and can experience a number of renovations.
  5.User can flexibly read and write data into RFID tags
• Feartures


  1. UHF RFID Tire tag,accord with EPC Class1 Gen2/ISO18000-6C
  2. The tag survives the high temperatures encountered in the tire retreading process and is sturdy enough to remain operational
  throughout the operating life of the tire.
  3. The tag has finished thousands of kilometers actual road test, did not lead to potential tire defects.

• Parameters of CM-101 tire tag

  Model	CM-101
  Protocol	EPC Class1 Gen2/ISO 18000-6C
  Chip	Alien H3
  Frequency	860—960MHZ
  Read distance	0.6m-3m
  Write distance	50% of reading distance
  Polarization	Linear
  Size	Length 92mm*Width 4mm *Antenna diameter 1mm
  Weight	0.3g
  Memory	96bits with 512bits user memory
  Operating Temp	-40c to +230c

•
•
•
•

1.white box:22*9*6mm,200pcs/white box ; carton: 52.5*22.5*15cm, 15 white box/carton

   or as your customized

2. by airplane or as your request
