Australian standard solar traffic LED trailer signs VMS

Detailed Product Description:

VMS Trailer

Display

1,Display Type: 5 Color LED Full Matrix
2,Display Size: 2600mm*1600mm
3,Matrix: 48*28

4,Enclosure: Aluminum IP54 equivalent
5,Screen: Non Glare UV polycarbonate
6,Photocell auto dimming

Power
1,Voltage: 12V
2,Solar panels: 3*125 watt panels
3,Batteries: 3*12V, 200AH deep cycle
4,solar controller: 20AMP
5,solar tilting system: Rotating 360 degree,

Product Specification
1,Length (Overall): 3600mm
2,Width (Travel position): 2000mm
3,Height (Travel position): 2850mm
4,Height (Max operating position): 3850mm
5,Weight: 850kg
6,Types: 185*75*14
7,Coupling: Quick release, 50mm
8,Ball Finish: Industrial Baked Enamel
9,3mm steel check plate

Controller and Programming

1,Programming options: Onsite, SMS, GPRS(remote control )

2,RSR232 serial direct connect

3,Software: Windows compliant free automatic software updates

4,Predefined images: 100

5,Large storage up to 100 individual messages with various page sizes

6,Onboard computer Mini PC for onsite programming

Optional

1 Speed Radar

You can use speed radar to detect the driving speed.

2 Electric actuator lifting system

Electric actuator lifting is used to replace hydraulic lifting, to lower noisy when lifting up and down, also more environmental-friendly.

Project case:  Melbourne Australia Solar trailer VMS
