MXTA Series Square Drive Hydraulic Torque Wrench for Hex Bolt
- shanghai
- T/T Credit Card
You May Like
-
Hex Bolt Type Low Profile Hydraulic Torque Wrench
-
700 Bar Square Drive Hydraulic Torque Wrench
-
700 Bar Low Profile Hydraulic Torque Wrench
-
Hydraulic Torque Wrench, Low Profile Hydraulic Torque Wrench
-
Hydraulic Hexagon Wrench, Hydraulic Torque Wrench Low Profile
-
Hydraulic Wrench, Low Profile Hexagon Hydraulic Wrench Quality Choice
Product Details
| Place of Origin | Jiangsu, China | Brand Name | FEIYAO | |
| Model Number | FY-MXTA | Type | Torque Wrench | |
| Material | Other, Alloy, Titanium aluminum alloy | Size | M16-M115 |
Product Description
Specifications
hydraulic torque wrench for hex bolt1.ISO9001:2008
2.Space materials,compact
3.High speed,double acting
4.OEM factory
MXTA series square drive hydraulic torque wrench for hex bolt
FEIYAO offers a variety of controlled tightening tools to best meet the requirements of your application. From mechanical torque multipliers to hydraulically driven square drive torque wrench, and low profile hydraulic torque wrenches. We offer the hydraulic torque tools you need for accurate and simultaneous tightening of multiple bolts.
Features
1.Very high torque-to-weight ratio
2.High speed,double acting operation
3.High degree of rotation angle
4.Never-jam mechanism
5.High repeatability,with accuracy ±3%
6.Slim nose radius and 360 degree swivel hose connection allow easier positioning in confined areas
7.Few moving parts means durability and low maintenance
8.Push button drive release;no tools needed to reverse square or allen key drives for tighening or loosening

Typical application
Parameter information
Model | FY- | FY- | FY- | FY- | FY- | FY- | FY- | FY- | FY- | FY- |
Max. Torque (N.M) | 1940 | 4763 | 8012 | 10704 | 15633 | 20782 | 28286 | 39584 | 50844 | 58673 |
Min.torque(N. M) | 139 | 340 | 572 | 765 | 1117 | 1484 | 2020 | 2827 | 3632 | 4263 |
Screw size(mm) | 24-55 | 32-75 | 41-85 | 46-95 | 55-105 | 60-115 | 65-130 | 75-145 | 95-170 | 105-185 |
Bolt size(M) | 16-36 | 22-48 | 27-56 | 30-64 | 36-72 | 39-80 | 42-90 | 48-100 | 64-120 | 72-130 |
axle | 3/4" | 1" | 1-1/2" | 1-1/2" | 1-1/2" | 2-1/2" | 2-1/2" | 2-1/2" | 2-1/2" | 2-1/2" |
L1 | 127 | 170 | 213 | 223 | 251 | 2774 | 309 | 320 | 358 | 375 |
L2 | 187 | 253 | 292 | 354 | 359 | 418 | 453 | 490 | 522 | 539 |
L3 | 106 | 145 | 168 | 206 | 210 | 250 | 260 | 290 | 305 | 315 |
H3 | 52 | 70 | 82 | 94 | 103 | 110 | 126 | 135 | 150 | 156 |
H2 | 77 | 101 | 127 | 138 | 147 | 163 | 192 | 205 | 214 | 220 |
H3 | 98 | 133 | 153 | 184 | 196 | 225 | 234 | 269 | 276 | 288 |
H4 | 169 | 201 | 200 | 281 | 185 | 326 | 328 | 354 | 358 | 373 |
R | 26 | 35 | 40 | 50 | 52 | 60 | 66 | 70 | 75 | 78 |
weight | 2.3 | 5.2 | 8 | 12 | 14.8 | 18.9 | 28 | 41.2 | 46.3 | 53.5 |
Brief introduction of FEIYAO

Established in 1978, Jiangsu Feiyao Machinery Manufacturing factory is an professional leading manufacturer of hydraulic tools in China. Such as PLC lifiting systerm, hydraulic cylinders, torque wrench, nut splitter, flange spreader, gear pullers, hydraulic pumps and accessories etc.
Our products have been widely sold to Europe, South-east Asia and Middle East, and have got high appreciation and trust from all our customers. Whenever you need hydraulic products, please rememmber our company is always your reliable friends.
Our well-equipped facilities and excellent quality control enables us meet customers' satisfaction. Besides, we have gained CE and ISO9001 certificates.
We warmly welcome all overseas customers to talk with us about business or other cooperations.
Any phone call, E-mali, Fax from you would be a beginning of happy cooperation.
