CLP-5002 500 Ton 45mm Stroke Single Acting Pancake Lock Nut Hydraulic Ram
- shanghai
- T/T
You May Like
-
FY-MXTA Series High Quality Square Drive Hydraulic Electronic Torque Wrench
-
FY-MXTA Series High Quality Square Drive Hydraulic Torque Control Wrench
-
FY-MXTA Series High Quality Square Drive Hydraulic Impact Wrench Torque Limiter
-
FY-MXTA Series High Quality Square Drive Hydraulic Torque Wrench M27 M30 M33 M39 Bolt
-
FY-MXTA Series High Quality Square Drive Hydraulic Wheel Nut Torque Wrenches
-
FY-MXTA Series High Quality Square Drive Hydraulic Tools Torque Wrench
Product Details
| Standard or Nonstandard | Standard | Structure | Piston Cylinder | |
| Power | Hydraulic | Body Material | Steel | |
| Maximum Stroke | 50mm | Place of Origin | Jiangsu, China | |
| Model Number | FY-CLP | Brand Name | FEIYAO |
Product Description
Specifications
pancake lock nut hydraulic ram1.Single acting load return
2.CE certificate
3.High quality, good price
4.Factory supply
CLP-5002 500 ton 45mm stroke single acting pancake lock nut hydraulic ram
FEIYAO general purpose cylinders are available in hundreds of different mechanical or hydraulic cylinder jack configurations. Whatever the industrial application; lifting, pushing, pulling and available in range of force capacities, stroke lengths or size restrictions. Single acting, hollow plunger, lock nut or low height, you can be sure that FEIYAO has the hydraulic cylinder jack to suit your high force application.
Features
1.Flat design for use in confined areas
2.When low height adn high force is required
3.The solution to lift the first few centimetres
4.Lock nut for mechanical load holding over a long period of time
5.Single-acting, load return
6.Optional special synthetic coating for improved corrosion resistance and lower friction for smoother operation to withstand side load forces up to 3% of rated cylinder capacity without scoring
7.Overflow port functions as a stroke limiter
8.CR-400 coupler and dustcap included
For the detailed technical specifications, pls contact us for related product catalogues
Application
Parameter information
Model | Pressure @700bar ton (KN) | Stroke (mm) | Effective area (cm2) | Oil capacity (cm3) | Closed Height (mm) A | Extending height (mm) B | Out diameter (mm) D | Weight (kg) |
FY-CLP-602 | 60(578) | 50 | 86.6 | 433 | 125 | 175 | 140 | 15 |
FY-CLP-1002 | 100(978) | 50 | 146.8 | 734 | 137 | 187 | 175 | 26 |
FY-CLP-1602 | 160(1511) | 45 | 231.3 | 1040 | 148 | 193 | 220 | 44 |
FY-CLP-2002 | 200(1955) | 45 | 285.6 | 1284 | 155 | 200 | 245 | 57 |
FY-CLP-2502 | 250(2489) | 45 | 366.8 | 1649 | 159 | 204 | 275 | 74 |
FY-CLP-4002 | 400(3822) | 45 | 559.5 | 2515 | 178 | 223 | 350 | 134 |
FY-CLP-5002 | 500(4977) | 45 | 730.6 | 3285 | 192 | 237 | 400 | 189 |
Accessories:
Brief introduction of FEIYAO
Established in 1978, Jiangsu Feiyao Machinery Manufacturing factory is an professional leading manufacturer of hydraulic tools in China. Such as PLC lifiting systerm, hydraulic cylinders, torque wrench, nut splitter, flange spreader, gear pullers, hydraulic pumps and accessories etc.
Our products have been widely sold to Europe, South-east Asia and Middle East, and have got high appreciation and trust from all our customers. Whenever you need hydraulic products, please rememmber our company is always your reliable friends.
Our well-equipped facilities and excellent quality control enables us meet customers' satisfaction. Besides, we have gained CE and ISO9001 certificates.
We warmly welcome all overseas customers to talk with us about business or other cooperations.
Any phone call, E-mali, Fax from you would be a beginning of happy cooperation.
Showroom
Workshop

Warehouse

Certification
