Single output 24V 100W waterproof led power supply LED driver
- 6000 Piece / Pieces per Month
- shenzhen
- T/T Credit Card
You May Like
-
High quality ac dc constant current led lighting driver power supply adapter 700ma 30w waterproof IP67 suply CC-40700C
-
Aluminum housing waterproof ip67 constant voltage 12V 150W led power supply, single output 12v led driver with 2 years warranty
-
Wholesale DC 24V 8.3A 200W LED Transformer For LED Strip Light waterproof
-
2 years warranty high quality led strip light driver constant voltage waterproof electronic 24v 200w led transformer
-
constant voltage DC24V 200W LED transformer
-
High power IP67 waterproof 200W 24V waterproof led driver 200w
Product Details
| Place of Origin | Guangdong, China | Brand Name | Shine | |
| Model Number | CV-24100C(coffee) | Output Power | Other, 100W | |
| Output Type | Single | Input Voltage | Other, 170-250VAC | |
| Output Voltage | 24V | Output Current | 4.2A |
Product Description
Specifications
1.Single output 24V 100W led driver2.CE RoHS approved
3.100% full load burn-in test
4.2 years warranty
24V single output series 100W waterproof led power supply constant voltage industrial led driver
| Product Specification |
Feature: |
·Suitable for LED lighting and LED sign applications |
·Protections: Short circuit / Overload / Over Voltage / Over Temperature |
·IP67 design for indoor or outdoor installations |
·Efficiency: 80% |
·100% full load burn-in test |
·Storage temperature: -40-80℃ |
·Operating temperature: -25-45℃ |
·Certificate: CE, ROHS |
·MTBF: Min250Khrs |
·Warranty: 2 years |
.Life time: 60,000 hours |
Specification: | ||
Model | CV-24100C(coffee) | |
OUTPUT | DC Voltage | 24±0.5VDC |
Rated power | 100W | |
Max current | 4.2A | |
INPUT | Voltage | 170-250VAC |
Frequency | 47 ~ 63 Hz | |
AC Current | 1.1A | |
Efficiency (Typ.) | 80% | |
PROTECTION | Overload | 20% exceed is allowing |
Short Circuit | Auto recovery | |
Over Voltage | ≤255V | |
Over temperature | ≤85Degree | |
OTHERS | Cooling | By convection |
Withstand voltage | 2200VAC | |
Dimension/Weight | 213*70*45mm/1150g | |
Packing/Carton Size | 19pcs/carton / 39.4*25.4*24.5cm | |
Cable | 0.75sq.mm. VDE wire 300mm | |
Housing Material | Aluminum | |
CE | CE Safety Standard | Compliance to EN61347-1:2008&EN 61347-2-13:2006 |
EMI conduction & radiation | Compliance to EN 55015: 2006+A1: 2007 EN 61547: 2004 | |
Harmonic Current | Compliance to EN 61000-3-2: 2006 EN 61000-3-3: 1995+A1: 2001+A2: 2005 | |
1. T/T West Union, 30% deposit after order confirmed, the balance before shipment.
2. Lead time: normally in 5-7 workdays after deposit received.
3. Sample policy: Samples are always available for each model. Deliver Immediately once payment received.
4. Shipping port: Shenzhen, China.
5. Discounts: We offer discount for big quantity.
1. For all your inquiries about us or our products, we will reply you in detail within 24 hours.
2. Well-trained and professional sales & after- sale services stuff who can speak fluent English.
3. OEM service is available. Can print your own logo on product, customized the retail box packing.
4. With experienced R&D engineers and strong ability to do ODM projects.
