DMC Mould Press Insulation Fittings For Power Transformer Equipment

 1.Application Scope: Our post insulators are widely used in 3.6kV~40.5kV AC electrical device and high voltage equipments under   frequency 100Hz.

 2. Service Condition: for indoor installation. Operating temperature: -5°C~45°C

 3. Structure: Post type, epoxy resin casting

 4. Electrical Characteristics:

 a. Rated Insulation Level:

     3.6/25/40kV, 7.2/32/60kV , 12/42/75kV, 24/68/125kV, 40.5/100/185kV

 b. Partial discharge: not more than 10pC at applied voltage 1.1Ur.

 c. Be capable of withstanding temperature cycle test without any damage.

 5. Material: high quality epoxy resin, which is nonflammable and self-extinguished.

 6. Mechanical characteristics:

 a. Always undergoes the tensile test, torsion test, compression test

 b. Mechanical strength is always tested and within the standard value:

2000N, 4000N, 6000N, 8000N, 10000N

12000N, 16000N, 20000N, 25000N, 30000N

c. Appearance:

Metal accessories of the post insulators are always assembled according to the drawing. Color of the post insulator is as per clients’ requirements.

The surface of epoxy resin post insulator must be smooth, flat, incomplete fillings, no air holes, no defects and flaws, such as crack and kink mark,

7. Manufacture Standard: GB/T 10305

 DMC Mould Press Insulation Fittings For Power Transformer Equipment
  :

We have a team who is in charge of packing.

The team consists of our skilful carpenters and experienced packing designers.

These enable our packing reasonable, safe and reliable.

• Your inquiry related to our product & price will be replied within 24hours
• Well-trained & experienced staff are to answer all your inquiries in English of course.
• Working time: 8:00am ~17:45pm, Monday to Saturday. (UTC+8).
• Provide perfect after-sale service,  if you got any question, please contact with us and we wll  solve your problem immediately.
• We have our own transportation department, goods can be delivered on time whenever they are ready.
• Your business relationship with us will be confidential to any third party.

1. Q: Minimum order quanlity?

     A: 3units

2. Q: Delivery time?

     A: 5~30 days (after order)

3. Q: Payment term?

     A: L/C or T/T

4. Q: Tell me more about the product information.

     A: Voltage Transformers&Current Transformers: up to 1000kV

          Dry-type Power Transformers: up to 35kV

          Switches: up to 35kV

          Trucks Matching Switchgears: up to 35kV

          Sensors: up to 35kV

          Insulating Articles: up to 1000kV

         Or you could send more the parameters of the product you need that help us to select suitable one for you.
