Home > Products > Geocell production line > China hot Sale geocell equipment YXGC-5000
China hot Sale geocell equipment YXGC-5000
- Qingdao china
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Yongxing | |
| Model Number | YXGC-5000 | Voltage | 380v | |
| Power | 30.6KW | Frequency | 50-60Hz | |
| Welding Area | customized | Dimensions | 5.0*2.0*2.2m | |
| Weight | 5.5ton | Usage | to produce geocell | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Geocell equipment YXGC-5000
Equipment Introduction:
1.The producing line adopts advanced YX series ultrasonic plastic welding machine ,VB series compiled program control machine
2.The whole machine adopts flexible composed design .It has advanced technology, reliable working condition and reliable performance. Praised by the users and exported to many countries and regions.
Equipment Features:
1.The equipment adopts the PLC control system, touching screen demonstration and parameter hypothesis.
2.Imported with the piezoelectric transducer from Germany with strong and steady output.
3.LCD,soft push on the control panel;
4.The molds adopt aviation aluminum alloy from USA, and they could be adjusted horizontally, fast and convenient.
5.The power is stronger and the transducer is more durable.
6. Frequency automatic tracking, multi parameter design
7. Welding sheet size: 5cm, 10cm, 15cm, 20cmx900cm,0-99 sheet can be set arbitrarily;
8. The air filtration system using 3 cubic refrigeration dryer;
9. Welding material :PP,PE,PVC.
Equipment Parameters:
Item | Specification | Item | Specification |
Welding Head (unit) | 15 | Weight (T) | 5.8 |
Output Power | 36.6KW | Power | AC380V N 50-60HZ |
Dimension (m) | 6.0*2.0*2.2 | Air Pressure | 0.6~0.9MPa |
Welding Distance | 220-1000mm |
Equipment products:
