PP Biaxial geogrid for Reinforced soil retaining wall
- Qingdao port China
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | LUYUAN | |
| Model Number | GG1515,GG2020,GG3030,GG4040 | Material | Plastic |
Product Description
Reinforced soil retaining wall
1.Description:
Plastic PP biaxial geogrids is an integrally formed structure,which especially designed for soil stabilization and reinforcement applications. EltGrid-PPBG biaxial geogrid is manufactured from Polypropylene,from the process of extruding,longitudinal stretching and transverse stretching.
2.Properties:
- High tensile strength at both longitudinal and transverse direction.
- High tension resistance,high plane torsion resistance modulus,good creep resistance and stable chemical nature.
- High mechanic damage resistance and durability and large friction factor with sandy stone.
- It can improve bearing force of foundation and increase diffusion angle.
Index Properties | Test Method | Unit | GG1515 | GG2020 | GG3030 | GG4040 |
MD TD | MD TD | MD TD | MD TD | |||
Polymer | -- | -- | PP | PP | PP | PP |
Minimum Carbon Black | ASTM D 4218 | % | 2 | 2 | 2 | 2 |
Tensile Strength@ 2% Strain | ASTM D 6637 | Kn/m | 5 5 | 7 7 | 10.5 10.5 | 14 14 |
Tensile Strength@ 5% Strain | ASTM D 6637 | Kn/m | 7 7 | 14 14 | 21 21 | 28 28 |
Ultimate Tensile Strength | ASTM D 6637 | Kn/m | 15 15 | 20 20 | 30 30 | 40 40 |
Strain @ Ultimate Strength | ASTM D 6637 | % | 13 10 | 13 10 | 13 10 | 13 10 |
Structural Integrity | ||||||
Junction Efficiency | GRI GG2 | % | 93 | 93 | 93 | 93 |
Flexural Rigidity | ASTM D 1388 | Mg-cm | 700000 | 1000000 | 3500000 | 10000000 |
Aperture Stability | COE Method | mm-N/deg | 646 | 707 | 1432 | 2104 |
Dimensions | ||||||
Roll Width | -- | M | 3.95 | 3.95 | 3.95 | 3.95 |
Roll Length | -- | M | 50 | 50 | 50 | 50 |
Roll Weight | -- | Kg | 39 | 50 | 72 | 105 |
MD denotes Machine direction. TD denotes transverse direction. | ||||||
Suitable for all kinds of dam and roadbed reinforcement, reinforcement, slope protection, the cave walls large airport, parking lot, wharf freight yard and other permanent bearing foundation reinforcement.
- Increase the road (to) the bearing capacity of the base, prolong the service life of road (ground).
- To prevent the road surface subsidence (ground) or crack, Keeping the floor neat
- to facilitate the construction, saving time, effort, shorten the construction period, reduce maintenance costs.
- To prevent the culvert cracks.
- Enhance soil, prevent soil erosion.
- Reducing cushion thickness, saving the cost.
- To support the stability of slope planting grass mat afforest environment.
- can replace the metal mesh, used in the coal mine false top network.
5.Benifits:
- Improving bearing capacity of foundation
- Preventing cracking and subsiding
- Convenient to construct, reducing cost and maintaining expense
6.Packing and storage:
packed in roll
7.Production and Construction
