High Reflectance Glass Car Rearview Auto Dimming Mirror With Backup Camera System

Specifications

3.5" car  rearview  auto dimming mirror with backup water-proof camera system

1. Auto dimming mirrror with  Led parking module  and  Built-in buzzer,detecting and alerting by bi-bi alarm

•Operating Voltage DC 9.0 -16.0 V ;

•High Reflectance>70%. Low Reflectance 6~10%;
•Maximum Current <450 milliamps;
•Operating Temperature -40C ~ +85C;
•Storage Temperature -40C ~  +100C;
•Time to change reflectance from 55% to 15% <6.0 seconds;
•Time to change reflectance from 15% to 55% <8.0 seconds;

•Temperature -40ºC~85 ºc (option function)

•Compass   -180º~179º

• Auto-dimming

• Compass display

• Temperature display

•3.5" OSD rearvirw image

2.Water-proof night vision camera

High-definition and 135 degree viewing angle

Sony CCD or CMOS lens
Waterproof
Easy installation without drilling hole

3. Mass order package

Technical Specification •Operating Voltage DC 9.0 -16.0 V ;

 •High Reflectance>70%. Low Reflectance 6~10%;
•Maximum Current <450 milliamps;
•Operating Temperature -40C ~ +85C;
•Storage Temperature -40C ~  +100C;
•Time to change reflectance from 55% to 15% <6.0 seconds;
•Time to change reflectance from 15% to 55% <8.0 seconds;

•Temperature -40ºC~85 ºc (option function)

•Compass   -180º~179º

• Auto-dimming

• Led parking module

• Built-in buzzer,detecting and alerting by bi-bi alarm

4. Factory view
