Home > Products > For Videojet cij parts > Ink manifold assembly 100-0370-203 for Videojet 430 460 46m 43S inkjet printer

Ink manifold assembly 100-0370-203 for Videojet 430 460 46m 43S inkjet printer

FOB Price

US$ 10.00 - 10.00 / Piece

1 Piece(Min. Order)

Port Huangpu port
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	For Videojet
Model Number	100-0370-203	Type	Other, ink manifold assembly, ink manifold assembly
Use	Other, for Willett	Printing Type	Inkjet Printer

Product Description

Description:

Part no: 100-0370-203

Part name: ink manifold assembly

Compatible to:Willett Videojet 400 sereis cij printer

Methods of delivery:by DHL,FEDEX,TNT,EMS,UPS

Delivery time:within 3 days after payment

	Top Moulding, Keypad and LCD
1-5	1 through 5 378297-07 Kit, door and keypad, Russian 1
	378297-10 Kit, door and keypad, Chinese
	378297-101 Kit, door and keypad, UK/USA
	378297-102 Kit, door and keypad, European
	378297-103 Kit, door and keypad, Turk/Scandinavian
	378297-105 Kit, door and keypad, Katakana
	378297-107 Kit, door and keypad, Bulgarian
	378297-108 Kit, door and keypad, East European
	378297-11 Kit, door and keypad, Arabic
	378297-115 Kit, door and keypad, Farsi
	378297-12 Kit, door and keypad, Korean
	378297-13 Kit, door and keypad, Thai
	378297-19 Kit, door and keypad, Greek
	378297-20 Kit, door and keypad, Hebrew
	378297-23 Kit, door and keypad, Polish
1	Keypad bezel
2	Keypad overlay
3	Keypad circuit assy.
4	Electronics compartment door
5	100-043S-148 Gasket - top door
6	378336 Backlight Inverter
7	100-043S-175 Keypad harness
8	100-043S-190 Display panel cover
9	500-0085-140 LCD Panel
10	100-043S-159 Keypad/LCD ribbon cable
	Connector Panel
1	100-043S-160 Switch LED Cable
2	100-043S-210 Switch Cable Assembly
3	500-0097-128 Mains Power Filter
4	100-043S-172 Mains Filter Ground Wire
5	100-043S-170 Mains cable assembly (International) , 217019 Mains cable assembly (US)
6	100-043S-130 Shaft encoder cable (with port)
7	100-043S-128 RS-232 cable (with port)
8	500-0076-133 Blanking plug, 18mm
9	500-0076-134 Blanking plug, 14mm
10	100-043S-129 Photo Cell Cable
11	500-0082-158 Switch
	Electronics Compartment
1	200-0390-102 PSU
2	200-043S-166 CPU board
3	200-043S-145 Fan filter assembly
4	200-0390-239 EHT module
5	100-043S-158 EHT cable assembly
6	200-043S-147 Thumb knob
7	flash memory chips
8	200-0430-160 I/O board
9	200-0430-161 Ink pump motor driver board
10	100-043S-137 Main Harness
11	100-043S-164 Gland plate gasket
12	100-043S-211 Fan assembly
13	200-0390-119 Fan fail PCB
14	200-043S-148 Fan grill assembly
15	100-043S-176 Power harness
	Printhead Assembly
1	100-0370-196 Front cover
2	100-0370-231 Lid switch thumbscrew
3	200-3900-135 Charge electrode/LED assembly
4	200-0430-141 Nozzle assembly, 60 micron
5	100-0430-155 Insert, lid switch
6	200-0390-235 Cover switch assy.
7	200-0430-162 Head heater manifold
8	521-0001-177 Pico valve
9	500-0031-180 O-ring 25.81 x 3.53 CS
10	100-0370-231 M2 5 x 6 cask head st. st. screw
11	part of 200-043S-207 Umbilical
12	100-0370-195 Rear cover
13	200-3900-298 Phase detector assy.
14	200-0430-131 EHT block assy.
NI	522-0080-226 22 meg EHT resistor (inside EHT block)
16	100-0470-273 Ground plate, EHT (0 V)
17	100-0430-115 Last chance filter
18	500-0122-125 Compression spring
NI	200-043S-207 Printhead assembly (includes items 3, 5 through 9, 11, 13, 14 and 15)
	FMS platform
1	100-0370-102 VMS restrictor block between V3 and FMS
2	204-0336-101 Venturi assembly
3	200-043S-244 FMS assembly
	378269 Mixer tank sensor kit (43s only) includes all 5 sensors
4	378277-03 Flush pump tube connector (red) includes gripper
5	500-0031-234 6.07 x 1.78 O-ring
6	500-0034-110 Non return valve
7	500-0047-133 Pressure damper
8	500-0041-296 Jaco nut
9	200-0430-146 Flush pump assembly
NI	100-0430-114 Flush pump diaphragm 1 inside flush pump
10	378277-01 Flush pump tube connector (black) includes gripper
NI	378277-02 Flush pump tube connector (green) on left side of flush pump,
	includes gripper
11	500-0047-131 Pre-pump filter, 30 micron
12	500-0047-134 inline filter, 8 micron use this part for both prehead
	filter and flush filter
13	500-0041-110 Festo tee
14	500-0047-130 Main ink system filter, 5 micron
15	100-0370-200 System manifold
16	500-0031-175 4.47 x 1.78 O-ring
17	378254 Pressure transducer (43s only) includes both O-rings
18	500-0031-164 Pressure transducer front O-ring
19	500-0031-201 Pressure transducer rear O-ring
20	100-0370-112 Printhead manifold
21	500-0031-117 1.78 x 1.78 O-ring
22	521-0001-174 Solenoid Valve, 3-port (Valves V3 and V7) white base
23	521-0001-175 Solenoid Valve, 3-port (V8) black base
24	521-0001-173 Solenoid Valve, 2-port (Valves V1, V2 and V6)
	V1 and V2 are shown on page 12-19.
NI	500-0031-231 Valve O-rings (20 pack)
NI	204-0346-101 75 micron VMS filter (10 pack) 1 tiny white filter in FMS

	Ink Bottles and Ink System Pump
1	200-0390-108 Pump
2	100-0470-198 Pump seal gasket
3	500-0031-249 O-ring (15.6/1.78)
4	100-043S-180 Down tube
5	500-0041-194 Jaco 1/8” tee
6	500-0031-250 O-ring (20.4/1.78)
7	100-043S-179 2x down tube adapter
8	500-0031-251 O-ring (14.0/1.78)
9-14	200-043S-250 Ink system kit
9	200-0466-143 Level detect assembly
10	100-0370-159 Level detect seal
11	100-0466-144 Ink tank manifold
12	100-043S-189 Solvent tank manifold
13	100-0430-139 Manifold gasket
14	100-0470-118 Solvent/ink tank
NI	NI 501-0002-101 1/8” tube, clear
NI	NI 501-0002-114 1/8” tube, green stripe
NI	NI 501-0002-113 1/8” tube, black stripe
NI	NI 501-0002-115 1/8” tube, yellow stripe
NI	NI 501-0002-131 6mm x 4mm PTFE tubing
	Ink filler caps
1	100-0470-191 Filler housing, ink
2	500-0031-241 O-ring (53.64/2.62)
3	100-0470-195 Cap retainer black
4	100-043S-194 Ink cap
5	500-0031-232 O-ring (45.69/2.62)
6	100-0470-308 Cap retainer white
7	100-043S-195 Top-up cap
8	100-0470-192 Filler housing, top-up
9	100-043S-188 Housing plate gasket
10	100-043S-181 Housing plate
11	100-043S-191 Housing nut
