LV3095 NEW Cheap OEM CMOS 2D Fingerprint Scanner Module
- Shenzhen
- Credit Card PayPal
You May Like
-
LV3095 NEW Cheap OEM CMOS 2D Optical Mark Reader with 4.4 g Lightweight
-
LV3095 2014 NEW Cheap OEM CMOS 2D Wide Format Scanner, Upgrade for Symbol 955SE
-
LV3095 Cheap OEM Barcode QR Scanner Module for PDA, Upgrade for Motorola 955SE
-
LV3095 Cheap OEM Barcode QR Reader Module for PDA, Upgrade for Motorola 955SE
-
LV3095 Cheap OEM Barcode 2D Scanner Module for PDA, Upgrade for Motorola 955SE
-
NEW LV4500 CMOS Mobile Phone 2D Barcode White LED Scanner, 10 mil Resolution, RS232/USB Interface
Product Details
Products Status | Stock | Type | Other, Barcode Scanner, Fingerprint Scanner Module | |
Scan Element Type | CMOS | Colour Depth | 32 Bit | |
Interface Type | USB, Other, USB, TTL - 232 ,USB(HID-KBW,Virtual Serial Port),DATAPIPE ,HID- POS) | Max Paper Size | A4 | |
Optical Resolution | 2500 | Scan Speed | up to 300 scans/sec | |
Brand Name | Longview | Model Number | LV3095 | |
Place of Origin | Guangdong, China |
Product Description
LV3095 NEW Cheap OEM
CMOS 2D Fingerprint Scanner Module
Advantages:
1.Seamless substitute for Motorola 955SE for their same bottom screw hole and size.
2.Upgrade your scanning application from 1D to 2D directly.
3. LV3095 is able to scan mobile phone screen 2D barcode
4. No need to change the mold, saving your huge costs to remake the mold
5. New starter to prepare for the brand new era of 2D barcode.
Features:
1.2D Barcode Decoder Chip:
The engine armed with the state-of-the art 2D barcode demonstrates unprecedented reading performance.
2.Two-In-One Design:
Seamless integration of CMOS image sensor and decoder board makes the engine small, lightweight and easy for integration.
3.High Performance & Ultra-Low Power Consumption:
The engine can read most 1D and 2D barcodes with a power consumption only one fourth that of a traditional engine.
4.All-Round Scanning Capability:
It can read barcodes on virtually any medium paper, plastic cards, mobile phones and LCD displays.
Image Sensor | 752x480 CMOS |
Illumination | Red LED 625 ±10 nm |
2D
Symbologies 1D | PDF417QR Code(Model 1/2, Micro),Data Matrix (ECC200,ECC000,050,080,100,140)
Code 128 ,EAN-13,EAN-8 ,Code 39,UPC-A,UPC-E ,Codabar ,Interleaved 2 of 5,ISBN/ISSN ,Code 93 ,UCC/EAN- 128 ,GS1 Databar,etc |
Precision | ≥ 5mil |
Depth of Field | UPC-A (13mil) 55mm -270mm Code 39 (20mil) 50mm -340mm PDF 417 (6.67mil) 70 mm-165 mm Data Matrix (10mil) 55 mm -180 mm QR Code (20mil) 35 mm -275mm |
Symbol Contrast | ≥ 30% |
Scan Angle | Roll: 360; Pitch: ±50; Skew: ±50° |
Field of View | Horizontal 36°; Vertical 23° |
Operating Temperature | - 20°C - +60 °C |
Storage Temperature | - 40°C - +8 0 °C |
Humidity | 5% - 95% (non-condensing) |
Ambient Light | 0 ~ 100000 lux (natural light) |
EVK3000 | Software development board for the LV3095, equipped with a trigger button, beeper and RS-232 & USB interfaces. |
RS-232 Cable Cables USB Cable | Used to connect the EVK3000 to a host device; equipped with a power connector. Used to connect the EVK3000 to a host device. |
Power Adaptor | Used to provide power for the EVK3000. Output: DC5V, 2A; Input: AC100~240V, 50~60Hz |
